OPERATING INSTRUCTIONS

Translation of the Original

ACCESSORIES

Venting valve

Dear customer,

Thank you for choosing a Pfeiffer Vacuum product. Your new Pfeiffer Vacuum accessory

should support you in your individual application with full performance and without

malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a

comprehensive and complete range of top-quality products and first-class service. With this

expertise, we have acquired a multitude of skills contributing to an efficient and secure

implementation of our product.

Knowing that our product must not interfere with your actual work, we are convinced that our

product offers you the solution that supports you in the effective and trouble-free execution of

your individual application.

Please read these operating instructions before putting your product into operation for the

first time. If you have any questions or suggestions, please feel free to contact info@pfeiffer-

vacuum.de.

Further operating instructions from Pfeiffer Vacuum can be found in the Download Center on

our website.

Disclaimer of liability

These operating instructions describe all models and variants of your product. Note that your

product may not be equipped with all features described in this document. Pfeiffer Vacuum

constantly adapts its products to the latest state of the art without prior notice. Please take

into account that online operating instructions can deviate from the printed operating

instructions supplied with your product.

Furthermore, Pfeiffer Vacuum assumes no responsibility or liability for damage resulting from

the use of the product that contradicts its proper use or is explicitly defined as foreseeable

misuse.

This document is the intellectual property of Pfeiffer Vacuum and all contents of this

document are protected by copyright. They may not be copied, altered, reproduced or

published without the prior written permission of Pfeiffer Vacuum.

We reserve the right to make changes to the technical data and information in this document.

2/16

Table of contents

1 About this manual 4

1.1 Validity 4

1.1.1 Applicable documents 4

1.1.2 Variants 4

1.2 Target group 4

1.3 Conventions 4

1.3.1 Instructions in the text 4

1.3.2 Pictographs 4

1.3.3 Labeling on the product 5

1.3.4 Abbreviations 5

2 Safety 6

2.1 General safety information 6

2.2 Safety instructions 6

2.3 Safety precautions 6

2.4 Proper use 7

2.5 Foreseeable improper use 7

2.6 Personnel qualification 7

3 Product description 8

3.1 Function 8

3.2 Scope of delivery 8

4 Installation and operation 9

4.1 Connecting venting valve 9

4.2 Operating venting valve 10

5 Recycling and disposal 11

6 Accessories, technical data and dimensions 12

6.1 Accessories 12

6.2 Technical data 12

6.3 Dimensions 12

EU Declaration of conformity 13

UK Declaration of Conformity 14

Table of contents

3/16

1 About this manual

IMPORTANT

Read carefully before use.

Keep the manual for future consultation.

1.1 Validity

These operating instructions are a customer document of Pfeiffer Vacuum. The operating instructions

describe the functions of the named product and provide the most important information for the safe use

of the device. The description is written in accordance with the valid directives. The information in these

operating instructions refers to the product's current development status. The document shall remain

valid provided that the customer does not make any changes to the product.

1.1.1 Applicable documents

Designation Document

Declaration of conformity A component of these instructions

Tbl. 1: Applicable documents

You can find this document in the Pfeiffer Vacuum Download Center.

1.1.2 Variants

●Venting valve, shielded, 24 V DC, AccessLink

1.2 Target group

This operating instructions is intended for persons who

●install,

●operate.

The work described in this document may be carried out only by people who have completed suitable

technical training (experts), or who have received equivalent training from Pfeiffer Vacuum.

1.3 Conventions

1.3.1 Instructions in the text

Usage instructions in the document follow a general structure that is complete in itself. The required ac-

tion is indicated by an individual step or multi-part action steps.

Individual action step

A horizontal, solid triangle indicates the only step in an action.

►This is an individual action step.

Sequence of multi-part action steps

The numerical list indicates an action with multiple necessary steps.

1. Step 1

2. Step 2

3. ...

1.3.2 Pictographs

Pictographs used in the document indicate useful information.

About this manual

4/16

Note

Tip

1.3.3 Labeling on the product

This section describes all existing labeling on the product along with its meaning.

D-35614 Asslar

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

VVVVVVVVVVVVVVVVVVVVVVVVVVVVVVVV

Mod. Venting Valve

24 V DC, G1/8

P/N PM Z01 295

Made in Germany JJJJ/MM

Rating plate (example)

The rating plate is laser-marked on the bottom side

of the housing.

Tbl. 2: Labeling on the product

1.3.4 Abbreviations

DN Nominal diameter as size description

ISO Flange: Connection in accordance with ISO 1609 and ISO 2861

LED Light emitting diode

WAF Width Across Flats

TC Turbopump electronic drive unit (turbo controller)

Tbl. 3: Abbreviations used in this document

About this manual

5/16

2 Safety

2.1 General safety information

The following 4 risk levels and 1 information level are taken into account in this document.

DANGER

Immediately pending danger

Indicates an immediately pending danger that will result in death or serious injury if not observed.

►Instructions to avoid the danger situation

WARNING

Potential pending danger

Indicates a pending danger that could result in death or serious injury if not observed.

►Instructions to avoid the danger situation

CAUTION

Potential pending danger

Indicates a pending danger that could result in minor injuries if not observed.

►Instructions to avoid the danger situation

NOTICE

Danger of damage to property

Is used to highlight actions that are not associated with personal injury.

►Instructions to avoid damage to property

Notes, tips or examples indicate important information about the product or about this docu-

ment.

2.2 Safety instructions

All safety instructions in this document are based on the results of the risk assessment carried out in

accordance with Low Voltage Directive 2014/35/EU. Where applicable, all life cycle phases of the prod-

uct were taken into account.

Risks during operation

CAUTION

Risk of injuries due to contact with vacuum when venting

While venting the vacuum pump there is a risk of minor injuries due to the direct contact of body parts

with the vacuum, e.g. hematomas.

►Do not fully unscrew the venting screw out of the housing during venting.

►Keep a distance from automatic venting device, such as venting valves.

2.3 Safety precautions

Duty to provide information on potential dangers

The product holder or user is obliged to make all operating personnel aware of dangers

posed by this product.

Every person who is involved in the installation, operation or maintenance of the product

must read, understand and adhere to the safety-related parts of this document.

Safety

6/16

Infringement of conformity due to modifications to the product

The Declaration of Conformity from the manufacturer is no longer valid if the operator

changes the original product or installs additional equipment.

●Following the installation into a system, the operator is required to check and re-evalu-

ate the conformity of the overall system in the context of the relevant European Direc-

tives, before commissioning that system.

General safety precautions when handling the product

►Observe all applicable safety and accident prevention regulations.

►Check that all safety measures are observed at regular intervals.

►Never disconnect plug connections during operation.

►Keep lines and cables away from hot surfaces (> 70 °C).

►Observe the unit protection degree prior to installation or operation in other environments.

►Do not carry out your own conversions or modifications on the unit.

2.4 Proper use

►Use the venting valve only for controlled venting on the designated Pfeiffer Vacuum turbopumps.

2.5 Foreseeable improper use

Improper use of the product invalidates all warranty and liability claims. Any use that is counter to the

purpose of the product, whether intentional or unintentional, is regarded as improper use; in particular:

●Connecting to vacuum pumps and units that are not designed for this purpose according to their

operating instructions

●Connecting to units with exposed live parts

2.6 Personnel qualification

The work described in this document may only be carried out by persons who have appropriate profes-

sional qualifications and the necessary experience or who have completed the necessary training as

provided by Pfeiffer Vacuum.

Training people

1. Train the technical personnel on the product.

2. Only let personnel to be trained work with and on the product when under the supervision of

trained personnel.

3. Only allow trained technical personnel to work with the product.

4. Before starting work, make sure that the commissioned personnel have read and understood

these operating instructions and all applicable documents, in particular the safety, maintenance

and repair information.

Safety

7/16

3 Product description

3.1 Function

The Pfeiffer Vacuum venting valve ensures automatic venting of a turbopump after shutting down or in

the event of a power failure.

Fig. 1: Layout of venting valve

1 Control cable with connecting plug 4 Protective plug

2 Protective cap 5 Valve body

3 Sealing ring

3.2 Scope of delivery

●Venting valve

●Sealing ring

●Sealing plugs

●Operating instructions

Product description

8/16

4 Installation and operation

4.1 Connecting venting valve

NOTICE

Property damage caused by unfiltered media supply

Using unfiltered media for the gas inlet of a vacuum pump may result in particle contamination. There

is a risk of damage to, and even destruction of, vacuum components.

►Install suitable filters from the Pfeiffer Vacuum accessories range upstream of the gas inlet, be-

fore you use ambient air or other unclean media.

Prerequisites

●Vacuum pump switched off and vented

Required tools

●Hexagon wrench, WAF 14

●Calibrated torque wrench (tightening factor ≤ 1.6)

123

Fig. 2: Connecting venting valve to HiPace Neo

1 Venting connection, turbopump 4 Connecting plug with Pfeiffer Vacuum logo

2 Venting screw 5 Turbopump accessory connection

3 Valve body

Fitting the venting valve

1. Unscrew the venting screw with sealing ring out of the turbopump by hand.

2. Screw the venting valve with the outlet side into the venting connection of the turbopump.

–Tightening torque: 2 Nm.

Connecting venting valve to turbopump

►Plug the control cable of the venting valve into one of the two accessory connections "C1" or "D1"

on the pump bottom part.

–Make sure that the Pfeiffer Vacuum logo on the connecting plug is facing up.

–The electronic drive unit software automatically resets existing configuration settings to "de-

fault" and automatically detects newly connected accessories.

Establish the venting gas supply

In case you want to use dry room air as venting gas, the venting valve is ready for operation immediate-

ly. Pfeiffer Vacuum recommends: Use a filter on the inlet side.

Installation and operation

9/16

If you wish to use a different inert gas (e.g. nitrogen N2) as the venting gas, follow the steps.

1. Provide an external venting gas supply with a maximum inlet pressure of 1,500 hPa absolute.

2. Connect the venting gas supply to the inlet side (1/8" thread) of the valve.

3. If required, use connection adapters from the valve accessories (not included in the scope of sup-

ply).

4.2 Operating venting valve

CAUTION

Risk of injuries due to contact with vacuum when venting

While venting the vacuum pump there is a risk of minor injuries due to the direct contact of body parts

with the vacuum, e.g. hematomas.

►Do not fully unscrew the venting screw out of the housing during venting.

►Keep a distance from automatic venting device, such as venting valves.

NOTICE

Damage to the turbopump due to non-permissibly fast pressure rise during venting

Non-permissibly high pressure rise rates place a significant load on the rotor and the magnetic bear-

ing of the turbopump. During venting very small volumes in the vacuum chamber or the turbopump,

there is a risk of uncontrollable pressure rises. This causes mechanical damage to the turbopump,

including potential failure.

►Observe the prescribed maximum pressure rise speed of 15 hPa/s.

►Avoid manual and uncontrolled venting of very low volumes.

►Where necessary, use a venting valve from the Pfeiffer Vacuum range of accessories.

Parameter Name Designation Setting

[P:012] EnableVent Enable venting 0 = no

1 = yes

[P:030] VentMode Venting mode 0 = Delayed venting

1 = No venting

2 = Direct venting

[P:068] CfgAccC1 Accessory connection C1 1 = Venting valve, closed without current

6 = Always "0"

7 = Always "1"

8 = Power failure venting unit

12 = Second venting valve

[P:069] CfgAccD1 Accessory connection D1 Functions, see [P:068]

Tbl. 4: Parameter settings in the electronic drive unit of the turbopump

Venting speed [P:720] Venting duration [P:721] Venting duration in the event of a power

failure

50% of rated speed 3600 s 3600 s

Tbl. 5: Factory settings for delayed venting in turbopumps

Installation and operation

10/16

Inhaltsverzeichnis

Andere Pfeiffer Vacuum Steuereinheit Handbücher

Pfeiffer Vacuum

Pfeiffer Vacuum TCP 350 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum OmniControl Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVL 063 P Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 500 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum UVH 040 CU Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVI 005 MI Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum DualGauge TPG 262 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 366 MAXIGAUGE Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum DVB Series Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum AVA 016 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 361 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum DVB 016 SX Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum HPU 001 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVB 016 S A/X Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum UDV 040 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum PM Z01 310 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum RME 005 A Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVR 116 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVB 16 P A Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum CENTERONE-TWO Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVA 016S Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum DCU 002 Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum EVL 016 P Bedienungsanleitung

Pfeiffer Vacuum

Pfeiffer Vacuum UVH 016 VI Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
