R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Issue 5.1 July 2019

User Manual

GPIB RF Multiplexer Module

(Model Nos. 10-740/740A)

pickeringtest.com pickering

SYSTEM 10/20

*Please contact Pickering for alternative

PXI/LXI/USB solutions

Page (II) R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Page (IV) GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre-Operation Checks...........................................................3.1

Hardware Installation ............................................................3.1

Software Installation .............................................................3.3

Reconguring the Driver Card to Your Application ...........3.4

Interconnecting RF Switching Modules ..............................3.6

Section 4

Programming Guide....................................................................4.1

Programming the Module .....................................................4.1

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Installation Problems ...........................................................6.1

Section 7

Maintenance Information............................................................7.1

Relay Lookup Tables.............................................................7.1

PCB and Component Layout................................................7.4

CONTENTS

Please use the hyperlinked text to navigate to the page required

Page (VI) R.F. MULTIPLEXER MODULE 10-740/740A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

R.F. MULTIPLEXER MODULE 10-740/740A

pickering

Page (VII)

GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the System 10/20 chassis are populated with blanking plates to prevent access

to user I/O signals that may be present. Blanking panels are available to order from Pickering in a

variety of slot widths. If the product is not used in this manner for example by using an extender card

then additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

Page (VIII) R.F. MULTIPLEXER MODULE 10-740/740A

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

R.F. MULTIPLEXER MODULE 10-740/740A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

GPIB RF Multiplexer Module 10-740A

ISSUE 5.2 JUL 2019

• Dual 8 to 1 R.F. Multiplexer with 150MHz

Bandwidth

• 50Ω Characteristic Impedance

• Conﬁgurable as 16 to 1 Multiplexer with

Reduced Bandwidth

• Front Panel Mounted BNC Plugs

• Front Panel Indicator LEDs

• Suitable for Many Screened Low Frequency

Applications

Common

Dual 8-Channel RF Multiplexer Mode

Alternative 16-Channel RF Multiplexer Mode

Model 10-740A is a dual 8 to 1 RF Multiplexer with a bandwidth

up to 150MHz. The 10-740A may also be congured (via internal

DIP switches) as a 16 to 1 multiplexer but with reduced RF

performance. The multiplexer has a characteristic impedance of

50Ω.

The 10-740A is also suitable for low frequency applications

requiring BNC coaxial switching. It may be operated as a

normal RF multiplexer (with only 1 channel selected at a time),

alternatively 2 or more channels may be simultaneously selected

(but with much reduced RF performance).

Applications include routing high frequency signals to and from

oscilloscopes, analyzers, signal generators and synthesizers,

video/audio switching, switching high frequency logic and many

other situations involving coaxial or guarded switching.

Programming

The multiplexer module is simple to program:

ARESET a Open all channels on device a

DELAY t Force a minimum delay of tmilliseconds

between two instructions

RESET Open all switches on all modules

VIEW? a View status of device a

CHAN a,c Select channel con multiplexer a.

When in dual 8 to 1 mode the address is

prexed by 1 or 2.

CHAN a,c,s Multi-channel selection argument s

allows

opening/closing of any combination

of channels, but with reduced RF

performance.

*Please contact Pickering for alternative

PXI/LXI/USB solutions

Page 1.2 R.F. MULTIPLEXER MODULE 10-740/740A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

RF Multiplexer Module – 10-740A

pickeringtest.com

Speciﬁcations

Switching Speciﬁcation

Characteristic Impedance: 50Ω

Maximum Frequency:

Rise Time:

Insertion Loss (<20GHz):

VSWR:

Isolation:

Crosstalk:

150MHz

2ns

<3dB

1:1.7

>55dB

>40dB

Maximum Voltage:

Maximum Power:

Maximum Switch Current:

Maximum Carry Current:

100V d.c.

10W

0.5A

1.2A

On Path Resistance:

Off Path Resistance:

Noise:

Differential Thermal Offset:

<250mΩ

>1011Ω

<-75dBm

<20µV

Capacitance, Open Channel:

Capacitance, Channel-Channel:

Capacitance, Open Channel-GND:

<0.1pF

<15pF

Switching Time: 15ms

Expected Life (Low power):

Expected Life (Max power):

>1x108operations

>5x106 operations

Mechanical Characteristics

All models conform to the 3U height (128mm) Eurocard standard

and are 160mm deep. Panel width for the 10-740A module is 4.2

Inches.

Connectors

The 10-740A RF Multiplexer Module is available with 50Ω front

panel connectors. Alternative connectors are available to order

such as 1.0/2.3, SMZ, Mini SMB or BT type 43 - Please consult the

sales ofce.

Operating/Storage Conditions

Operating Conditions

Operating Temperature:

Humidity:

Altitude:

0°C to +55°C

Up to 95% non-condensing

5000m

Storage and Transport Conditions

Storage Temperature:

Humidity:

Altitude:

-20°C to +75°C

Up to 95% non-condensing

15000m

0 dB

-0.8 dB

-1.2 dB

-1.6 dB

-2.0 dB

-2.4 dB

-2.8 dB

-0.4 dB

-3.2 dB

50MHz 100MHz 150MHz

10-740A-501 INSERTION LOSS: (Dual 8 to 1 Mode)

-50 dB

-60 dB

-70 dB

-80 dB

-90 dB

-100 dB

100MHz 200MHz 300MHz

10-740A-501 ISOLATION: (Dual 8 to 1 Mode)

Insertion Loss Plot for 10-740A-501, 300MHz MUX

1.6

1.4

1.2

1.0

50MHz 100MHz

10-740A-501 VSWR (Dual 8 to 1 Mode)

-30 dB

-50 dB

-60 dB

-70 dB

-80 dB

-90 dB

-40 dB

100MHz 200MHz 300MHz

10-740A-501 CROSSTALK: (Dual 8 to 1 Mode)

Worst Case (Adjacent

Channel)

Best Case

VSWR Plot for 10-740A-501, 300MHz MUX

Isolation Plot for 10-740A-501, 300MHz MUX

Crosstalk Plot for 10-740A-501, 300MHz MUX

Additional Speciﬁcation (16 to 1 Mode)

Maximum Frequency: 40MHz

Andere Handbücher für SYSTEM 10

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Pickering Steuereinheit Handbücher

Pickering

Pickering PXI 40-787 Bedienungsanleitung

Pickering

Pickering PXI 40-664A Bedienungsanleitung

Pickering

Pickering 40-290-021 Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-562A Bedienungsanleitung

Pickering

Pickering 40-781 Bedienungsanleitung

Pickering

Pickering 40-561A Bedienungsanleitung

Pickering

Pickering 40-618A Bedienungsanleitung

Pickering

Pickering PXI 30 A Bedienungsanleitung

Pickering

Pickering 40-656A Bedienungsanleitung

Pickering

Pickering PXI 40-535 Bedienungsanleitung

Pickering

Pickering PXI 40-710 Bedienungsanleitung

Pickering

Pickering 45-542 Bedienungsanleitung

Pickering

Pickering PXI 40-510 Bedienungsanleitung

Pickering

Pickering 40-553A Bedienungsanleitung

Pickering

Pickering 4x-585A Bedienungsanleitung

Pickering

Pickering 40-884 Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-560A Bedienungsanleitung

Pickering

Pickering 40-520 Bedienungsanleitung

Pickering

Pickering 41-735 Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering 40-870 Bedienungsanleitung

Pickering

Pickering 41-765 Bedienungsanleitung

Pickering

Pickering 40-670A Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
