ROSE DISPLAYS CLEAR LOCKING HOOKS Bedienungsanleitung

Clear Locking Hook™Instruction Sheet

Flex

Step 1 Step 2 Step 3

Step 1 side view Step 3 side view

RAN-Base-S

RAN-Base-D

Instructions For Hanging

Step 1

Place open end of hook through pre-punched hole

in poster or graphic, or though clip on holder.

Step 2

Look closely at the opening in hook. It resembles a

racetrack. Place post on end of hook into top end

of the racetrack. DO NOT FORCE the post into

the hole.

Step 3

Once post has been inserted into top end of the

race track, flex hook slightly to allow post to slide

into lower end of the racetrack. This will lock the

post in place.

Note: To unlock the hook- reverse the process.

Instructions for Clear Locking

Hook & Clear Anchor Assembly:

25-0100 single hook used with clear base.

Step 1

If using this assembly you should also have clear

anchor bases. (Parts shown to right) Place open

end of hook through anchor- from the top of the

anchor base.

Step 2

See individual holder instructions for hanging.

Clear Locking Hook

25-0200 Double

Clear Locking Hook

25-0100 Single

PARTS

35 Congress Street, Salem, MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

The Clear Locking Hook is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products. Part #99INSCLH

Clear Locking Hook™Instruction Sheet

Flex

Step 1 Step 2 Step 3

Step 1 side view Step 3 side view

RAN-Base-S

RAN-Base-D

Instructions For Hanging

Step 1

Place open end of hook through pre-punched hole

in poster or graphic, or though clip on holder.

Step 2

Look closely at the opening in hook. It resembles a

racetrack. Place post on end of hook into top end

of the racetrack. DO NOT FORCE the post into

the hole.

Step 3

Once post has been inserted into top end of the

race track, flex hook slightly to allow post to slide

into lower end of the racetrack. This will lock the

post in place.

Note: To unlock the hook- reverse the process.

Instructions for Clear Locking

Hook & Clear Anchor Assembly:

25-0100 single hook used with clear base.

Step 1

If using this assembly you should also have clear

anchor bases. (Parts shown to right) Place open

end of hook through anchor- from the top of the

anchor base.

Step 2

See individual holder instructions for hanging.

Clear Locking Hook

25-0200 Double

Clear Locking Hook

25-0100 Single

PARTS

The Clear Locking Hook is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products. Part #99INSCLH
