www.swannsecurity.com

Product Code: SW242-4AI Monitoring Kits & Recording

Amazing features, yet easy to use!

• Easy remote viewing - detects IP address automatically

• Built-in high speed Search Engine (Max. 128x)

• Superior video quality new H.264 compression technology & VGA adapter

• Easy to use on-screen 3D operating system, menus, remote & mouse control

• Pentaplex operation for simultaneous live monitoring, recording, playback,

archiving and remote image access

MONITORING

Warranty

month

DVR4-8500AI™

4 Channel Digital Video Recorder

The ultimate ‘artificial intelligence’ security protection

for your business

Superior Video Quality

NEW

Compression Technology

H.264

LEVEL

Easy set-up

& operation from

Embedded

OS Interface

Records

up to 4 months

continuously from

4 cameras

Pre-Installed

250GB Seagate

Hard Drive

Download free CMS

software to

see multiple

locations at once

Easy remote

viewing setup

Superior Video Quality

DMX (H.264 Level)

Compression

Technology

Simple to use

Mouse Operation

(mouse not included)

Easy back-up

to DVD/RW

Smart Search

Allows you to

highlight an area &

search in that area

Color

www.swannsecurity.com

Please note that the information contained within this document is subject to change without notification.

MONITORING

Technical Specifications

DVR4-SecuraNet™

Compression: H.264 Level (Professional MPEG4 DMX-V3)

Data Size: 0.2KB/frame

Image Size: D1 LEVEL (704x480), CIF LEVEL (352x240)

Recording Frame: NTSC 120FPS / PAL 100FPS

TV Out (BNC): 2CH (1.0Vpp,75Ω)

VGA Out: 1CH (1024x768)

*Can be used TV out simultaneously

Compression: G.726 (ADPCM 8KHz Sampling)

Input / Output: 2CH Line in / 1CH Line Out

Live: Real-time Remote Max, 120FPS Transmission

Search: Smart Search, Statistics Search

Backup: Remote Backup, Clip Bank Player

GUI: 3D Graphic User Interface

HDD: Built-in 250GB HDD,

Max, 3 Internal EIDE HDD Installable

- can fit 3 hard drives

Recording Mode: Continuous, Scheduled, Motion Detection,

Sensor Event, Manual

Search Mode: Max, Speed 128X Search, Date/Time, Statistic, Event,

Motion Detection: Motion Detection Area (22x15 block)

& Sensitivity Setup

Mouse: USB Mouse supported

Package Contents

• DVR4-8500AI™

• 250GB Seagate Hard Drive (fitted)

• BNC to RCA Video Cable 3ft (1m)

• Power Adapter

• BNC to RCA Adapters x 4

• Manual & Quick Start Guide

• Theft Deterrent Stickers x 4

*Requires broadband internet connection

DVR4-8500AI™

4 Channel Digital Video Recorder

The ultimate ‘artificial intelligence’ security protection for your business
