Demonstrating the

Jailhouse Hypervisor Virtualization

on the Sitara AM572x Reference Design

TI Design: http://www.ti.com/tool/tidep-0095

2

Jailhouse Overview

Linux

Bare Metal

or

RTOS

Jailhouse Hypervisor

Hardware

CPU 0 CPU 1

Root Cell (Non-root) Cell

Application

Inmate

Application

The Jailhouse Linux-based partitioning hypervisor is an open-source project:

https://github.com/siemens/jailhouse

Jailhouse Initialization on AM572x

Linux

ARM A15

Core 0

Linux

Jailhouse Hypervisor

Linux

Jailhouse Hypervisor

ARM A15

Core 1

ARM A15

Core 0

ARM A15

Core 1

ARM A15

Core 0

ARM A15

Core 1

Root Cell Root Cell

Inmate

Cell

Jailhouse Hypervisor Demonstration Overview

Processor SDK Jailhouse Hypervisor Wiki:

http://processors.wiki.ti.com/index.php/Processor_SDK_Jailhouse_Hypervisor

Set Up Hardware Install Software

Boot Board

With Prebuilt

SD Card

Enable Jailhouse

Validate

Root Cell and

Inmate Functions

Set Up Hardware

Set Up Hardware Install Software

Boot Board

With Prebuilt

SD Card

Enable Jailhouse

Validate

Root Cell and

Inmate Functions

Supported Hardware

AM5728 EVM AM5728 IDK

http://www.ti.com/tool/TMDSEVM572X http://www.ti.com/tool/TMDXIDK5728

Set Up Hardware

Host

ETH

USB

Serial

ETH

Install Software

Set Up Hardware Install Software

Boot Board

With Prebuilt

SD Card

Enable Jailhouse

Validate

Root Cell and

Inmate Functions

Jailhouse Software

•jailhouse.ko kernel module is located in the directory:

/lib/modules/4.9.28-<gitid>/extra/driver

•jailhouse.bin hypervisor is located in the directory:

/lib/firmware

•Jailhouse management tools are located in the following directories:

/usr/local/libexec/jailhouse

/usr/sbin
