Thermo Scientific 2870 Betriebsanleitung

User Manual

Reciprocal Shaking Water Baths

Model 2870/2871 (25) and 2872/2873 (50)

Operating and Maintenance Manual 3177892 Rev K

Visit us online to register your warranty

www.thermoscientific.com/warranty

Thermo Scientific

MANUAL NUMBER 3177892

K 31074 5/14 Updated model chart in Section 3 ccs

J 29773/BA-797 11/13 Added Declaration of Conformity ccs

I 25227/BA-667 5/09 Probe, half coupling - pg 24 ccs

H 25448/BA-670 4/09 Added UL required info ccs

G 24808 9/08 Revised water specifications ccs

F 23496, 23443, 23196 6/06 consolidated w/ 3177689 240V manual, removed CE symbol and declaration, updated electrical specs

E -- 5/05 New manual number and manufacture location (was 36100127 [34002571])

D -- 11/01 Added caution “acidic and caustic substances...” - pg 7

C -- 7/01 Updated electrical specifications - pgs 2, 18, 26, 27

B -- 3/00 Set hi-limit thermostat instructions, and updated resistance measurements for current motor - pgs 6, 12

A -- 6/99 Initial release

REV ECR/ECN DATE DESCRIPTION By

Preface

Reciprocal Shaking Water Baths i

Note The 240V units described in this manual were designed specifically for the

European market and are supplied with a European style power cord. For

domestic use, a U.S. style power cord (P/N 3178034) must be ordered

separately. s

Thermo Scientificii Reciprocal Shaking Water Baths

Preface

Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual may result

in damage to the unit, injury to operating personnel, and poor equipment performance. ▲

Caution All internal adjustments and maintenance must be performed by qualified service personnel. ▲

Material in this manual is for information purposes only. The contents and the product it describes are subject to change

without notice. Thermo Fisher Scientific makes no representations or warranties with respect to this manual. In no event

shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual.

Thermo Scientific Reciprocal Shaking Water Baths iii

Preface

Important operating and/or maintenance instructions. Read the accompanying text carefully.

Potential electrical hazards. Only qualified persons should perform procedures associated with this symbol.

Equipment being maintained or serviced must be turned off and locked off to prevent possible injury.

Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be damaged by

elevated temperatures.

Marking of electrical and electronic equipment, which applies to electrical and electronic equipment falling

under the Directive 2002/96/EC (WEEE) and the equipment that has been put on the market after 13 August

2005.

This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment

(WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Thermo Fisher Scientific has contracted

with one or more recycling/disposal companies in each EU Member State European Country, and this product

should be disposed of or recycled through them. Further information on Thermo’s compliance with this

directive, the recyclers in your country and information on Thermo products will be available at

www.thermofisher.com.

✔Always use the proper protective equipment (clothing, gloves, goggles, etc.)

✔Always dissipate extreme cold or heat and wear protective clothing.

✔Always follow good hygiene practices.

✔Each individual is responsible for his or her own safety.

Thermo Scientificiv Reciprocal Shaking Water Baths

Preface

Do You Need Information or Assistance on

Thermo Scientific Products?

If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:

1-740-373-4763 Direct

1-800-438-4851 Toll Free, U.S. and Canada

1-877-213-8051 FAX

http://www.thermoscientific.com Internet Worldwide Web Home Page

service.led.marietta@thermofisher.com Tech Support Email Address

Certified Service Web Page

Thermo Fisher Scientific

401 Millcreek Road, Box 649

Marietta, OH 45750

Our staff can provide information on pricing and give you quotations. We can

take your order and provide delivery information on major equipment items or make

arrangements to have your local sales representative contact you. Our products are listed on the

Internet and we can be contacted through our Internet home page.

Our staff can supply technical information about proper setup, operation or

troubleshooting of your equipment. We can fill your needs for spare or replacement parts or

provide you with on-site service. We can also provide you with a quotation on our Extended

Warranty for your Thermo Scientific products.

Whatever Thermo Scientific products you need or use, we will be happy to discuss your

applications. If you are experiencing technical problems, working together, we will help you

locate the problem and, chances are, correct it yourself...over the telephone without a service

call.

When more extensive service is necessary, we will assist you with direct factory trained

technicians or a qualified service organization for on-the-spot repair. If your service need is

covered by the warranty, we will arrange for the unit to be repaired at our expense and to your

satisfaction.

Regardless of your needs, our professional telephone technicians are available to assist you

Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by

telephone or fax. If you wish to write, our mailing address is:

International customers, please contact your local Thermo Scientific distributor.

Sales Support

Service Support

www.unitylabservices.com

Reciprocal Shaking Water Baths vThermo Scientific

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Unpacking and Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Water Level Regulator (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Explanation of Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1

Periodic Safety Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-2

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1

Part Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1

Temperature Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-1

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-1

Accessory Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-2

Schematics and Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-3

Section 1

Section 2

Section 3

Section 4

Section 5

Section 6

Section 8

Section 7

Section 9

Section 10

Section 11

Section 12

Section 13

Introduction

Your satisfaction and safety are important to Thermo and a complete

understanding of this unit is necessary to attain these objectives.

As the user of this apparatus, you have the responsibility to understand the proper

function and operational characteristics of your bath. This instruction manual

should be thoroughly read and all operators given adequate training before

attempting to place this unit in service. Awareness of the stated cautions and

warnings, and compliance with recommended operating parameters — together

with maintenance requirements — are important for safe and satisfactory

operation. The unit should be used as described in this manual and for its

intended purpose; alterations or modifications will VOID THE WARRANTY.

Warning As a routine laboratory precaution, always wear safety glasses when

working with this apparatus. ▲

This product is not intended, nor can it be used, as a sterile or patient connected

device. In addition, this apparatus is not designed for use in Class I, II or III

locations as defined by the National Electrical Code.

Reciprocal Shaking Water Baths 1-1Thermo Scientific

Reciprocal Shaking Water Baths 2-1Thermo Scientific

Unpacking and Damage

Save all packing material until unit is put into service. This merchandise was

carefully packed and thoroughly inspected before leaving our factory.

Responsibility for safe delivery was assumed by the carrier upon acceptance of the

shipment; therefore, claims for loss or damage sustained in transit must be made

upon the carrier by the recipient as follows:

1. Visible Loss or Damage: Note any external evidence of loss or damage on the

freight bill, or express receipt, and have it signed by the carrier's agent.

Failure to adequately describe such external evidence of loss or damage may

result in the carrier's refusing to honor your damage claim. The form

required to file such claim will be supplied by the carrier.

2. Concealed Loss or Damage: Concealed loss or damage means loss or damage

which does not become apparent until the merchandise has been unpacked

and inspected. Should either occur, make a written request for inspection by

carrier's agent within fifteen (15) days of the delivery date; then file a claim

with the carrier since the damage is the carrier's responsibility.

If you follow the above instructions carefully, we will guarantee our full support

of your claim to be compensated for loss or concealed damage.

DO NOT — FOR ANY REASON — RETURN THIS UNIT WITHOUT

FIRST OBTAINING AUTHORIZATION. In any correspondence to Thermo,

please supply the nameplate data, including catalog number and serial number.
