Vacmaster VQ1220PF Bedienungsanleitung

VQ1220PF

1250W20L

IPX4

Original Instructions

VQ1220PF

Suzhou Cleva Electric Appliance Co., Ltd.

No.8 Ting Rong Street

Suzhou Industrial Park, Suzhou

Jiangsu Province, China

www.cleva-europe.com

Made in P.R.C

VQ1220PF

1250W20L

IPX4

Original Instructions

VQ1220PF

Suzhou Cleva Electric Appliance Co., Ltd.

No.8 Ting Rong Street

Suzhou Industrial Park, Suzhou

Jiangsu Province, China

www.cleva-europe.com

Made in P.R.C

11 12

15 16

TABLE OF CONTENTS

SECTION PAGE

Symbols......................................................................................................................................... 4

Safety Information ......................................................................................................................... 5

Unpacking and Checking Carton Contents ................................................................................... 8

Assembly....................................................................................................................................... 9

Operation .................................................................................................................................... 10

Maintenance................................................................................................................................ 12

Troubleshooting........................................................................................................................... 13

Technical Data ............................................................................................................................. 14

Recycling and Disposal ............................................................................................................... 14

Thank you for purchasing this Vacmaster® wet and dry vacuum cleaner. Feel condent that with

Vacmaster®you are obtaining a high quality product engineered for optimal performance. This

vacuum cleaner is suitable for use with both liquids and dry materials.

FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS.

SYMBOLS

Caution

Read instruction manual.

Appliance in which protection against electric shock does not rely on

basic insulation only but in which additional safety precautions are

provided, such as double insulation or reinforced insulation, there

being no provision for protective earthing or reliance upon installation

conditions.

SAFETY INFORMATION

READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE

USING THIS VACUUM CLEANER.

When using the equipment, a few safety precautions must be

observed to avoid injuries and damage. Please read the complete

operating manual with due care. Keep this manual in a safe

place so that the information is always available. If you give

the equipment to any other person, give them these operating

instructions as well. We cannot accept any liability for damage or

accidents which arise due to a failure to follow these instructions

and the safety information.

• Never leave the appliance switched on unattended, if you leave

the work area, switch the appliance off or unplug it from the

power supply.

• Do not vacuum or use this Wet and Dry vacuum cleaner near

ammable liquids, gases or explosive vapours like gasoline or

other fuels, lighter uids, cleaners, oil-based paints, natural gas,

hydrogen, or explosive dusts like coal dust, magnesium dust,

grain dust or gun power. Sparks inside the motor can ignite

ammable vapours or dust.

• This vacuum cleaner is not suitable for the vacuuming of

asbestos or asbestos dust.

• Do not vacuum anything that is burning or smoking, such as

cigarettes, matches, or hot ashes.

• Ensure the hose and connections are always pointed away from

the users face, hair, ears and eyes during operation and never

direct the nozzle towards persons or animals.

• Clear the working area of any items or possessions that you do

not wish to be vacuumed before operation.

• Keep cord away from heated surfaces.

• Do not expose to rain. Store indoors.

• Do not unplug by pulling on the cord. To unplug, grasp the plug,

not the cord.

• Do not use with damaged cord, plug or other parts.

• Do not pull or carry by cord, use cord as handle, close a door on

cord, or pull cord around sharp edges or corners.

• Do not handle the plug or vacuum cleaner with wet hands.

• Frequently check that the oat valve positioned underneath the

motor is able to move freely.

• Do not use this vacuum cleaner with a torn lter or without the

lter installed.

• Do not allow to be used as a toy. Close attention is necessary

when used by or near children.

• To reduce the risk of injury from accidental starting, unplug

power cord before changing or cleaning lter.

• Unplug from power supply when not in use and before carrying

out maintenance.

• Do not cover the ventilation openings. Do not vacuum with any

ventilation openings blocked; keep free of dust, lint, hair or

anything that may reduce air ow.

• Keep hair, loose clothing, ngers, all parts of body away from

openings and moving parts.

• If the supply cord is damaged, it must be replaced by the

manufacturer, a qualied service agent or similarly qualied

persons in order to avoid a hazard.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of

the appliance in a safe way and understanding the hazards

involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children

without supervision.

• For additional protection: It is recommended that this vacuum

cleaner can be used in conjunction with residual current device

(RCD) with a rated residual current of 30mA or less.

• If foam or liquid escapes from the machine, switch off

immediately.

• Check the oat valve regularly for moving freely and examine it

for signs of damage.

• For user servicing, the machine must be dismantled, cleaned

and serviced, as far as is reasonably practicable, without

causing risk to the maintenance staff and others. Suitable

precautions include decontamination before dismantling,

provision for local ltered exhaust ventilation where the machine

is dismantled, cleaning of the maintenance area and suitable

personal protection.

• Perform a technical inspection at least annually, consisting of,

for example, inspection of lters for damage, air tightness of the

machine and proper function of the control mechanism.

• Besides the operating instructions and the binding accident

prevention regulations valid in the country of use, observe

recognized regulations for safety and proper use.

• When dust removers are used, the rate at which air is

exchanged in the room must be adequate if the exhaust air from

the vacuum cleaner is blown into the room (please observe

regulations valid in your country).

• Before starting work, the operating staff must be informed on

- use of the vacuum cleaner

- risks associated with the material to be picked up

- safe disposal of the picked up material.

• Before transporting the collection tank, close all the locks. Do

not tilt the cleaner if there is liquid in the collection tank. Do not

use a crane hook to lift the cleaner.

• When using an extension lead, check the minimum cross-

sections of the cable:

WARNING: When carrying out service or repair operations,

all contaminated items which cannot be satisfactorily cleaned

are to be disposed of; such items shall be disposed of in

impervious bags in accordance with any current regulation

for the disposal of such waste.

Cable length Cross section

< 16 A < 25 A

up to 20 m 1.5 mm2 2.5 mm2

20 to 50 m 2.5 mm2 4.0 mm2

When using as blower:

• Direct air discharge only at work area.

• Do not use Wet/Dry Vacuum as a sprayer.

• Do not direct air at bystanders.

• Keep children away when blowing.

• Wear safety goggles.

UNPACKING AND CHECKING CARTON

CONTENTS

1 Carry Handle 7 Suction Port 13 Crevice Tool

2 Power Head 8 On/Off Switch 14 Hard Floor Nozzle

3 Accessory Storage 9 Blowing Port 15 Reusable Cloth Filter(pre-installed)

4 Latch 10 Power Cord Storage

Hooks 16 Foam Filter

5 Caster 11 Suction Hose 17 Screw (x6)

6 Container 12 Extension Wand (x3) 18 Instruction Manual

ASSEMBLY

NOTE: A Phillips screwdriver is required.

1) Remove all the contents from inside of the vacuum cleaner container.

2) Attach the carry handle into the slots located on the top of the power head. Secure them with

supplied screws (Fig. 1).

3) Turn the container upside down and insert the feet with casters into the slots and apply

pressure until they click into place. Secure them with supplied screws (Fig. 2).

4) Your vacuum cleaner comes ready for dry vacuum cleaning with the reusable cloth lter pre-

installed. If the reusable cloth lter is not installed, refer to page 10.

5) For wet vacuuming, replace the reusable cloth lter with the foam lter supplied. If the foam

lter is not installed, refer to page 10.

6) Secure the power head back on the container using the 2 side latches. Insert the locking end of

the hose into the suction port of the container (Fig. 3).

7) Choose the desired accessories and/or extension wands and push t onto the hose nozzle.

8) Choose the desired accessories and/or extension wands and push t onto the hose nozzle.

OPERATION

1. Switching On/Off

Connect the mains plug to a suitable power outlet.

Position Status

I on

O off

2. Wet & Dry Vacuum Operation

WARNING! ENSURE YOU READ, UNDERSTAND AND APPLY SECTION

ENTITLED ‘SAFETY INFORMATION’.

1) Verify that the correct lter is installed for wet or dry vacuuming and the container latches are

secured.

2) Secure the locking end of the hose into the vacuum suction port.

3) Push the desired accessories onto the hose nozzle.

4) Plug the power cord into a power outlet.

5) Turn on the motor by assigning the switch to the “I” ON position.

6) Once you have completed vacuuming, switch to the “O” OFF position and unplug the power

cord from the power outlet.

For Dry Vacuuming:

WARNING: BEFORE INSTALLING, REMOVING OR CLEANING THE VACUUM

CLEANER FILTER, ENSURE THAT THE POWER CORD IS UNPLUGGED AND

SWITCHED OFF.

1) To prepare your vacuum cleaner for dry vacuuming, install the reusable cloth lter over the lter

cage ( ①) making sure the cage is covered (Fig. 4 & 5).

2) The elasticated opening should form a tight seal around the lter cage base.

IMPORTANT: Check the lter regularly for optimal performance. An old or blocked lter will reduce

suction performance.

For Wet Vacuuming:

1) To prepare your vacuum cleaner for wet vacuuming, remove the dry use reusable cloth lter.

2) Carefully install the supplied foam lter over the internal lter cage, making sure the whole cage

is covered (Fig. 6 & 7).

WARNING! DO NOT USE THE REUSABLE CLOTH FILTER FOR WET

VACUUMING.

Andere Handbücher für VQ1220PF

Inhaltsverzeichnis

Andere Vacmaster Staubsauger Handbücher

Vacmaster

Vacmaster VJF912PF 0202 Bedienungsanleitung

Vacmaster

Vacmaster DVTB204 0201 Bedienungsanleitung

Vacmaster

Vacmaster VMVQ1220SS Bedienungsanleitung

Vacmaster

Vacmaster VJH1211PF 0203 Bedienungsanleitung

Vacmaster

Vacmaster Orson Lite VSE2101EU Bedienungsanleitung

Vacmaster

Vacmaster VMVK1630SWC Bedienungsanleitung

Vacmaster

Vacmaster VK1650SWD 950091 Bedienungsanleitung

Vacmaster

Vacmaster MVOA407S Bedienungsanleitung

Vacmaster

Vacmaster PROFESSIONAL VJF608PF 0202 Bedienungsanleitung

Vacmaster

Vacmaster VJH1612PF 0202 Bedienungsanleitung

Vacmaster

Vacmaster VOC508S Bedienungsanleitung

Vacmaster

Vacmaster VJH1211PF 0204 Bedienungsanleitung

Vacmaster

Vacmaster VQ1530SFDC Bedienungsanleitung

Vacmaster

Vacmaster VJ607 Bedienungsanleitung

Vacmaster

Vacmaster VOC809PF Bedienungsanleitung

Vacmaster

Vacmaster VQ1115P Bedienungsanleitung

Vacmaster

Vacmaster VWM510 Bedienungsanleitung

Vacmaster

Vacmaster RESPIRA UC0501 Bedienungsanleitung

Vacmaster

Vacmaster VF408 Bedienungsanleitung

Vacmaster

Vacmaster VSH01 Bedienungsanleitung

Vacmaster

Vacmaster VJ507 Bedienungsanleitung

Vacmaster

Vacmaster VFB511B 0201 Bedienungsanleitung

Vacmaster

Vacmaster VOM205P Bedienungsanleitung

Vacmaster

Vacmaster VP321 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
