Agilent Technologies 7693A Bedienungsanleitung

7693A Automatic Liquid Sampler Supplies

uick Reference Guide

Agilent Supplies for Agilent Instruments

Agilent Technologies is committed to optimizing

your laboratory's productivity. As part of this

long-term committment, we have designed our

supplies to match our instruments precisely.

You get consistent results and optimum

instrument performance, all day, every day.

For your convenience, the reference list below

contains the most commonly ordered supplies

and parts.

Continued on the next page.

Description Part No. Notes

7693A Replacement Parts and Supplies

Gripper finger caps, 16/pk G4514-60710 eed occasional replacement;

keep a spare set on hand.

Injector mounting post G4513-20561 eeded if one injector is to be moved

between the front inlet and the rear inlet.

Dual parking post for autosampler 05890-61525 Provides a convenient place to park

your injector while performing

inlet maintenance.

eedle support insert, standard G4513-40525 When working frequently with dirty

samples, replace this part regularly to

maintain smooth syringe movement.

eedle support insert, on-column G4513-40529

7693A vial trays with colored labels, 3/pk with 12 label tags (4 colors) G4525A Extra set is very useful for working

on the bench and then exchanging with

racks on autosampler

Vial rack label kit G4525-60701

Vial rack labels kit, red, 3/pk G4525-60702

Vial rack labels kit, yellow, 3/pk G4525-60703

Vial rack labels kit, green, 3/pk G4525-60704

ALS main cable assembly G4514-60610 Provides added convenience in moving

injector between front and rear inlets;

eliminates unplugging and replugging

cable in back of instrument.

Agilent Blue Line Autosampler Syringes for 7693A ALS

Syringe, 1 µL, fixed needle, 23/42/Cone G4513-80229 Plunger in needle design provides

accuracy for small volume injections.

Syringe, 5 µL, fixed needle, 23-26s/42/HP G4513-80206 Fitted plunger, fixed tapered needle.

Syringe, 5 µL, on-column, removable needle, barrel only G4513-80207 For on-column injections; requires needle.

Replacement needle, 0.32 mm on-column, 5 µL syringe, 3/pk G4513-80214

Replacement needle, 0.25 mm on-column, 5 µL syringe, 3/pk G4513-80217

Amber screw top vials with write-on spot, 100/pk 5182-0716 Amber for light-sensitive samples.

Blue screw caps, PTFE/red silicone septa, 100/pk 5182-0717

Clear, silanized screw top vials, 100/pk 5183-2070 Silanized for active or "sticky" compounds.

2 mL Wide Opening Crimp Top Glass Vials

on-assembled crimp top convenience pack, 500/pk

Includes clear crimp top vials, silver aluminum crimp caps,

PTFE/red rubber septa in 6 drawer storage box

5181-3400

Clear crimp top vials, 100/pk 5181-3375

Amber crimp top vials with write-on spot, 100/pk 5181-3376 Amber for light-sensitive samples.

Silver-tone aluminum crimp caps, PTFE/red rubber septa, 100/pk 5181-1210

Syringe, 10 µL, PTFE tip, fixed needle, 23-26/42/HP G4513-80203 Recommended for best precision and

accuracy; PTFE-tipped plunger gives

lowest carryover.

Syringe, 10 µL, fixed needle, 23-26s/42/HP G4513-80204 For general use; fitted plunger and

tapered needle

Syringe, 10 µL, PTFE tip, removable needle, 23-26/42/HP G4513-80233 Both plunger and needle can be replaced

for extended use.

Replacement needle for 10 µL syringe, 23-26/42/HP, 3/pk G4513-80231

Syringe, 25 µL, PTFE tip, fixed needle, 23/42/HP G4513-80228

Syringe, 50 µL, PTFE tip, fixed needle, 23/42/HP G4513-80221

Syringe, 100 µL PTFE tip, fixed needle, 23-26s/42/HP G4513-80222

Agilent Blue Line Syringes for Enhanced Sample Handling Carriage (G4521A)

Syringe, 250 µL, PTFE tip, fixed needle, 23/42/HP G4513-60560 250 µL size is more precise at lower

volumes and more versatile.

Syringe, 500 µL, PTFE tip, fixed needle, 23/42/HP G4513-60561 500 µL size is more popular; dispenses

solvent quicker.

For a complete listing of syringes, replacement needles, and replacement PTFE tip plungers,

go to www.agilent.com/chem/syringes

2 mL Wide Opening Snap Top Glass Vials

Pre-assembled clear screw top vial convenience pack, 100/pk

Includes clear screw top vials, blue screw caps, PTFE/red silicone septa

5182-0553

Pre-assembled amber screw top vial convenience pack, 100/pk

Includes amber screw top vials with write-on spot, green screw caps,

PTFE/red silicone septa

5182-0554 Amber for light-sensitive samples.

Pre-assembled clear screw top vial convenience pack, 100/pk

Includes clear screw top vials, blue screw caps, PTFE/silicone septa

5182-0557

on-assembled screw top vial convenience pack, 500/pk

Includes clear screw top vials, blue screw caps, PTFE/silicone septa

in a 6 drawer storage box

5182-0734

on-assembled screw top vial convenience pack, 500/pk

Includes clear screw top vials with write-on spot, blue screw caps,

PTFE/red silicone rubber septa in 6 drawer storage box

5182-0867

Clear screw top vials, 100/pk 5182-0714

Agilent Blue Line Autosampler Syringes for 7693A ALS

Description Part No. Notes

Crimping and Decapping Tools

Electronic crimper, 11 mm, with 4.8v rechargeable battery pack and charger 5062-0207 Ideal for preparing large runs of samples

in crimp vials.

Electronic decapper, 11 mm, with 4.8v rechargeable battery pack and charger 5062-0209 Ideal for sample recovery or recycling

of large quantities of vials.

Manual crimper, 11 mm 8710-0979

Manual decapper, 11 mm 5181-1213

Continued on the next page.

To learn more about Agilent's complete offering

of parts and supplies for your 7693A ALS:

Visit www.agilent.com/chem/7693Asupplies

Contact your local Agilent Representative

Contact your local Agilent Authorized Distributor

Visit www.agilent.com/chem/contactus

to find an Agilent customer center in your country

Agilent Technologies shall not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this

material. Information, description, and specifications in this

publication are subject to change without notice.

Printed in U.S.A. August, 2009

5990-4586E

2 mL Wide Opening Snap Top Glass Vials

on-assembled snap top vial convenience pack, 500/pk

Includes clear snap top vials, clear polypropylene snap caps,

PTFE/red silicone septa in a 6 drawer storage box

5182-0547 Crimp caps may also be used on

snap cap vials.

Clear crimp/snap top vials, 100/pk 5182-0544

Amber crimp/snap top vials with write-on spot, 100/pk 5182-0545 Amber for light-sensitive samples.

Green polyethylene caps, clear PTFE/red silicone septa, 100/pk 5182-3457

Microvolume Inserts for Wide Opening Vials

250 µL glass inserts with polymer feet and mandrel interior, 100/pk 5181-1270

250 µL pulled-point glass inserts, 100/pk 5183-2085

400 µL glass flat bottom inserts, 500/pk 5181-3377

Shell Vials

Clear, glass shell vials and caps, 200/pk 5190-1570 ew economical choice for use with

7693A autosamplers.

Wash Vials (also for standards, diluents)

4 mL wash vials with fill markings and caps, 25/pk 5182-0551 Autosampler holds 15 wash vials, but unit

is shipped with a starter pack of 10.

Diffusion caps for 4 mL vials, 12/pk 07673-40180 Eliminates septum coring

with repeated entry.

Septa for 4 mL vials, 144/pk 9301-1031

Vial Accessories

Rack for 12 mm, 2 mL vials, 5/pk 9301-0722 Holds 50 vials

Barcode labels numbered 1 to 1000, 1000/pk 5958-9450

Agilent offers an extensive selection of vials, caps and septa in various types, materials and colors.

For a complete listing, go to www.agilent.com/chem/vials

Description Part No. Notes
