Daewoo FLR00046 Bedienungsanleitung

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Contents

Page No.

2 Contents

3 Reading and Storing the User Manual

3 Important Safety Instructions for Proper Use

6 Explanation of Symbols

7 Description of Parts –Overview

7 Description of Parts –Accessories

7 Description of Parts –Cylinder Detail

8 Assembling Your Vacuum Cleaner

8 Attaching the Flexible Hose

8 Attaching the Telescopic Tube & Floor Tool

9 Using Your Vacuum Cleaner

9 Using the Crevice and Upholstery Multi Tool

10 Using the Power/Speed Controller

10 Emptying Your Vacuum Cleaner

11 Removing the Dust Compartment Filters

13 Removing the Outlet Hepa Filter

14 Replacing the Dust Compartment Filters

17 Replacing the Outlet Hepa Filter

18 Care and Maintenance of Your Vacuum Cleaner

18 Recommended Filter Cleaning Intervals

19 Technical Specification

19 Plug Wiring Information

19 Customer Support

20 Troubleshooting Guide

20 Recycling Information

Back Page Warranty Information

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

READING AND STORING THE USER MANUAL

Before using this product, please read through this manual

carefully paying particular attention to the safety instructions.

Failure to do so may result in personal injury or damage to the

product.

Carefully save this instruction manual for future reference. Ensure the

user manual is included when passing the product on to any third

parties.

IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE

Whilst using electrical appliances, basic safety precautions should

always be followed.

•Read and familiarise yourself with all operating

instructions before using this Vacuum Cleaner.

•Before plugging your unit into the mains, visually check

that the unit is intact and has not suffered any transit

damage.

•Check that the voltage indicated on the data plate

corresponds with that of the local network before

connecting the appliance to the mains power supply.

•This appliance can be used by persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved.

•Children shall not play with the appliance.

•Keep the appliance and its cord out of reach of children

less than 8 years when it is energised or cooling down.

•DO NOT immerse the appliance or its cord in water or any

otherliquids.

•DO NOT leave the appliance unattended during use.

•DO NOT leave the appliance unattended whilst connected

to the mains supply.

•DO NOT use this appliance outdoors.

•It is imperative to unplug the power cord after the

appliance has been used, before it is cleaned and whilst

being repaired.

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

•Repairs to electrical appliances should only be performed

by a qualified electrician. Improper repairs may place user

at serious risk.

•DO NOT operate this appliance with a damaged plug or

cord, after a malfunction or after being dropped or

damaged in any way.

•Regular, periodic checks should be carried out on the

mains cable to ensure no damage is evident. Should there

be any signs of damage the appliance should not be used.

•If the power cable is damaged, it should only be replaced

by the manufacturer or a suitable qualified after-sales-

service in order to avoid a hazard

•DO NOT allow the mains cable to hang over sharp edges

or come in contact with hot surfaces.

•Allow the unit to cool before storage.

•Before cleaning and/or emptying the dust compartment,

disconnect the appliance from the mains supply and allow

to cool.

•This appliance is intended for household use only and

should not be used for industrial purposes.

•DO NOT use any accessories or attachments with this

appliance other than those supplied or recommended by

supplier.

•DO NOT use this appliance for anything other than its

intended use.

•DO NOT push objects into any openings as damage to the

appliance and/or electric shock may occur.

•Unplug after each use. Grasp the plug, not the cord.

•DO NOT pull or carry the Vacuum Cleaner by the electrical

cord, use the handle provided.

•Ensure fingers and other objects are never placed in any

part of the vacuum cleaner. Clothing or hair may become

trapped if the vacuum is used improperly.

•Keep hair, loose clothing, jewellery, fingers and all parts of

the body away from openings and moving parts.

•Keep all air vents clear and free of dust, lint, hair and

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

anything else that may reduce airflow.

•Avoid directing the appliance towards naked flames as the

air discharged may extinguish gas fires or pilot lights and

may disturb ashes in open fires.

•DO NOT Vacuum water or any other liquids with this

vacuum.

•DO NOT Vacuum hot ashes or lit cigarettes, etc.

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Explanation of Symbols

The following warning symbols or words are used in this instruction manual:

Products labelled with UK Conformity Assessment identifies

products conforming to UK statutory requirements.

Products labelled with this symbol conform to applicable provisions

of the European Economic Area.

You should now recycle your waste electrical goods and in doing

so help the environment. This symbol means waste electrical

products at the end of their useful life should not be disposed of

with normal household waste and not sent to landfill. Please

ensure it is taken to a suitable facility for disposal. Check with

your Local Authority or retailer for recycling advice or visit

www.recycle-more.co.uk enter your postcode to find out your

nearest recycling site.

This symbol provides useful additional information on the use

of this product.

This symbol indicates that the supply uses an alternating current

mains supply.

This symbol identifies voltage and the current rating for direct

current.

WARNING!

This symbol indicates that the appliance is electrically double

insulated and therefore does not require an earth connection.

This designates a hazard with moderate risk, which may result

in severe injury or damage to the product if not adhered to.

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Description of Parts –Overview

Description of Parts –Accessories

Description of Parts –Cylinder Detail

1.Cyclonic Filter

2.Cylinder

3.On/off button

4.Rear Hepa Filter Cover

5.Power/speed controller

6.Mains cable & plug

7.Cylinder release button

8.Cable retract button (press to retract cable)

9.Wheels (x2)

10.Dust compartment

11.Air intake/hose connector

12.Floor tool

13.Crevice & Upholstery multi tool

14.Flexible hose

15.Hose connector

16.Air control valve

17.Tool connector

18.Telescopic Tube

19. Filter cover

20. Cyclonic filter

21. Dust release catch

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Assembling Your Vacuum Cleaner

CAUTION Ensure that the vacuum cleaner is not connected to the mains supply

before using the attachments.

Attaching the Flexible Hose (14) to the Vacuum Cleaner

Attach the Flexible Hose (14) onto the vacuum cleaner by pushing the Hose

Connector (15) into the Air Intake (11) and rotating anticlockwise, arrowed

below:

To remove the hose, rotate the Hose Connector (15) clockwise and pull out.

Attaching the Telescopic Tube (18) and Floor Tool (12)

1.Push the Tool connector (17) into the top of the Telescopic Tube (18) as shown

below:

2.Extend the Telescopic Tube (18) to the desired length by pushing the catch

down and extending.

3.Attach the Floor Tool (12) to the other end as shown above.

Tool Connector (17)

Telescopic Tube (18)

Floor Tool (12)

Flexible Hose (14)

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using Your Vacuum Cleaner

1.Fully reel out the Mains Cable and Plug (6) from the vacuum cleaner, being

careful not the pull the cable out beyond the red mark but after the yellow

mark.

2.Insert the mains plug into the nearest socket.

3.Press the On/off button (3) to power up the vacuum.

Adjust the lever on the Floor Tool (12) according to the type of floor being

cleaned. Push the lever down for use on hard floors (i.e. non carpeted), pull the

lever up for vacuum cleaning carpets:

Using the Crevice & Upholstery Multi Tool (13)

Attach the Crevice & Upholstery Multi Tool (13) onto the Telescopic Tube (18) to

clean carpet edges, upholstered furniture and hard to get at areas:

If the Telescopic Tube (18) is not required, attach the Crevice & Upholstery

multi tool (13) or the Floor tool (12) directly to the Tool connector (17), this useful

whilst cleaning soft furnishings, stairs, etc. as below:

Left:

Adjust the lever on the

Floor Tool for carpeted or

hard floors:

Up for carpets

Down for hard floors

Left: Attached the Crevice

& Upholstery multi tool to

clean carpet edges

Right: Fold the brush down

to clean hard to get at

areas and upholstery.

Left: Attached the Crevice

& Upholstery multi tool to

the Hose. Use the brush to

clean upholstery.

Right: Attached the

Floor tool to the Hose to

clean the stairs.

Tornado Cylinder 700W Cyclonic Vacuum

Model No.: FLR00046

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using the Power/Speed Controller (5)

This control is useful for varying the suction

power. Push the control downwards to

reduce power whilst cleaning Laminate,

Vinyl floor, etc. and push the control

upwards to increase suction power for

carpets, rugs, etc.

Emptying Your Vacuum Cleaner

WARNING! Always disconnect the cleaner from the mains power supply

before cleaning. 1.Once the dust level reaches the ‘MAX’

mark (arrowed left) on the Dust

Compartment (10) it will need emptying

and the filters cleaned.

WARNING! DO NOT continue to use your vacuum cleaner once the ‘MAX’

mark has been reached as permanent damage may occur to the appliance.

2.To empty the cleaner, first remove the

Cylinder (2) as shown below and right:

a. Press the Cylinder Release Button (7).

b.Lift the Cylinder (2) away from the cleaner.

Inhaltsverzeichnis

Andere Daewoo Staubsauger Handbücher

Daewoo

Daewoo RC-900M Bedienungsanleitung

Daewoo

Daewoo DAVC 90-30L Bedienungsanleitung

Daewoo

Daewoo RC-382A Bedienungsanleitung

Daewoo

Daewoo RC-7005S Bedienungsanleitung

Daewoo

Daewoo TORNADO F1 Bedienungsanleitung

Daewoo

Daewoo RCC-250R-1 Bedienungsanleitung

Daewoo

Daewoo RC-2006SV Bedienungsanleitung

Daewoo

Daewoo RCC-120R-1 Bedienungsanleitung

Daewoo

Daewoo RCC-260 Bedienungsanleitung

Daewoo

Daewoo RC-4008BA Bedienungsanleitung

Daewoo

Daewoo RC-800 Bedienungsanleitung

Daewoo

Daewoo RC-7004F Bedienungsanleitung

Daewoo

Daewoo RC-350 Bedienungsanleitung

Daewoo

Daewoo RC-220 Bedienungsanleitung

Daewoo

Daewoo RC-407 Bedienungsanleitung

Daewoo

Daewoo CYCLONE DIGI ONE Bedienungsanleitung

Daewoo

Daewoo HURRICANE CAT 5 Bedienungsanleitung

Daewoo

Daewoo RCC-11GR EU Bedienungsanleitung

Daewoo

Daewoo DAAVC800-15L Bedienungsanleitung

Daewoo

Daewoo TORNADO PET Bedienungsanleitung

Daewoo

Daewoo RC-360 DB EU Bedienungsanleitung

Daewoo

Daewoo RCG-100 Bedienungsanleitung

Daewoo

Daewoo RC-172 Bedienungsanleitung

Daewoo

Daewoo DALVC18-15L Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
