Daewoo RC-850B Bedienungsanleitung

VACUUM CLEANER

RC-850B

READ AND KEEP THIS

■Thank you for purchasing this vacuum cleaner.

■For proper operation, please read this manual before using.

OWNER'S MANUAL

,,,,,







RC-850B(¿ -ALSARACO) 99.9.23 9:29 PM ˘ ` 1

1. ASSEMBLY

DESCRIPTION AND USING

A. DUST METER • How to check the DUST METER

Operate the cleaner with MAX power and keep the wide suction

brush apart from the floor.

• If the red indicator of the DUST METER appears,

– Empty the cloth filter or change the paper filter bag.

– In case the hose is blocked with a large object, remove it.

• When cleaning with the crevice tool or the dusting brush, the red

indicator may apear. In this case, continue cleaning.

B. HOSE HANDLE • Power control

C. CORD REWIND

BUTTON

D. POWER CORD • Connect to the same voltage as shown on the rating label.

• To plug or unplug, grasp the plug body. Do not hold or pull the

cord.

E. ON/OFF BUTTON

F. CLEANING TOOLS • Crevice tool

• Dusting brush

G. HOSE ADAPTER • When the separating the hose from the body, pull the hose

adapter as pressing the button.

H. KEEPING • Pipe holder

RC-850B(¿ -ALSARACO) 99.9.23 9:29 PM ˘`2

2. USING MODEL RC-850B

B C D

BUTTON

PIPE HOLDER

CREVICE

TOOL

DUSTING

BRUSH

ROTATE

GROOVE

DUST

COVER

HOSE

WIDE SUCTION

BRUSH HANDLE

UP HOLSTERY

NOZZLE

RC-850B(¿ -ALSARACO) 99.9.23 9:29 PM ˘`3

This vacuum cleaner should only be used for normal dry houshold dust and dirt.

The manufacturer cannot be held responsible for any damage caused by use or operation of the

cleaner contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can

be accepted for any possible damage.

PRECAUTIONS FOR SAFE USE

RED MARK

HOSE

• Do not vacuum areas which contain moisture

or water and inflammable matter, needles,

pins, razor blades, matches, cigarette-ends,

etc., since they may damage the cleaner or

filter bag or make fire.

• When rewinding the power cord, hold the

plug body before pressing the cord rewind

button to prevent whipping.

• Do not pull the power cord out beyond the

specified length.

• Make sure a filter bag and a motor protection

filter are always inserted. • This product provided with a cable which, if

damaged, must be replaced by a repair shop

auhorized by the manufacturer since special

tools are required.

• This hose (Model RC-850B) contains

electrical connections.

– Do not use to suck up water.

– Do not immerse in water for cleaning.

– The hose should be checked regularly and

must not be used if damaged.

• Do not pull the dust cover back excessively.

In case the dust cover is taken out of the body.

Fit it in place.

RC-850B(¿ -ALSARACO) 99.9.23 9:29 PM ˘`4

REPLACING THE FILTER

Grille

Filter

• Open the grille and take the filter out of the grille.

• Replace the soiled filter by the new one.

REPLACING THE FILTER BAG

Filter bag

holder

Guide

Bottom hook Board

Dust cover

• Open the dust cover and push the filter bag holder in the direction of the arrow mark, and then

take out the filter bag.

• When inserting the filter bag, place the board of the filter bag between the two guides and insert

the lower part of it into the bottom hooks and fix the upper part of it with the filter bag holder.

• The dust cover can not be closed completely when the filter bag is set wrong.

• If DAEWOO filter bag is not reserved. PHILIPS paper filter bag (OSLO series) may be used.

RC-850B(¿ -ALSARACO) 99.9.23 9:30 PM ˘`5

Please check each item below if you have trouble with your cleaner.

Before checking, ensure the the cleaner is unpluged from the power supply.

BEFORE ASKING FOR SERVICE

PROBLEM CHECK POINT MEASURE

• Suction power is weak. • Filter bag

• Hose

• If it is filled with dust, change

it.

• If clogged or blocked,

remove the object.

• The cleaner does not work. • Is the hose adapter inserted

into the suction opening of

the cleaner completely?

• When the filter bag is full or

blocked or any of the

accessories are blocked,

the overheating protection

for the motor is activated

automatically.

• Insert it completly.

• Switch off and unplug the

cleaner and check the dust

bag and accessories and

remove any blockages.

The cleaner can be switched

on again after about 30

minutes.

• Power cord does not rewind.

• Power cord is not pulled out

of the cleaner

• Power cord

• Pull the power cord out a

little and press the cord

rewind button.

• Do not pull it by force

Rewind it a little by pressing

the cord rowind button and

pull it out.

RC-850B(¿ -ALSARACO) 99.9.23 9:30 PM ˘`6

SPECIFICATIONS

Model RC-850B

Rating 220V/50Hz

Input watt Max 1600 W

Weight (Body) 5.2 kg

Dimension (L x H x D) 474 x 221 x 283 mm

Cord Length 6 m

RC-850B(¿ -ALSARACO) 99.9.23 9:30 PM ˘`7
