Eneo DLR3-16N/160CDV Bedienungsanleitung

Operating Instructions

Digital Video Recorder

Models: DLR3-16N/160CDV,

DLR3-16N/410CDV,

DLR3-16N/660CDV

DLR3-16N/XX

Safety instructions

EMC class

This video recorder (DVR) is a class A device in accordance with EN 55022.

This device may cause interference to other equipment in domestic use. In such cases the persons opera-

ting the DVR are required to provide appropriate countermeasures, for which they themselves bear the cost.

►

Importance of these Operating Instructions

Please read the safety instructions and the other information contained in the Operating Instructions before

connecting up and operating the DVR.

The Operating Instructions should be kept in a safe place for later reference.

►

Ambient conditions for the DVR

The DVR should be protected against excessive heat, dust, damp and vibration.

The DVR may only be operated at temperatures between +5°C and +40°C, and up to a maximum air

humidity of 90%.

The DVR may only be operated indoors, and must be protected against incursion of water and damp.

►

Care of the DVR

Never switch on the DVR when damp has penetrated it. In such cases, have the DVR checked by a qualied

service engineer.

Do not place any heavy objects on the DVR.

Never cover over the DVR's vents.

Never insert metal objects or any other items into the vents. This may permanently damage the DVR.

The housing may only be opened by authorised persons. Repairs may only be carried out by qualied

service personnel.

The DVR must be disconnected from the power supply before its housing is opened.

►

Getting started with the DVR

When laying the connecting cables, make sure no weight is placed on them, that they are not kinked or

damaged, and that no damp can penetrate them.

►

Cleaning the DVR

The housing of the DVR may only be cleaned with a damp (not wet) cloth,

Use only a mild detergent. Do not use solvent-containing detergents or petrol. This could permanently

damage the surface nish.

►

Spare parts

Use only original spare parts from Videor Technical GmbH.►

DLR3-16N/XX

Table of contents

Overview 7

Package contents 7

Basic functions 7

Features 7

Requirements for operation 7

Control options 7

Connections on the rear 8

Front panel controls 9

Key to controls 10

Function buttons 10

PTZ camera functions 10

Playback functions 10

Menu structure 11

Getting started 13

Checklist for DVR operation 13

Switching on the DVR 14

Accessing the Setup menu 14

Switching off the DVR 14

Administration 15

Saving your system setup 15

Loading your system setup 15

Deleting recordings 15

Downloading software updates 16

Hiding from specic users 16

Restoring factory defaults 16

Determining the memory requirement of a recording 17

Searching for recordings 18

Using calendar search 19

Using event log search 20

Using text-in search 21

Using motion search 23

Copying recordings 24

Menu descriptions – Setup menu 25

System – Information 26

System – Date/Time 27

System – Storage 28

System – User 30

System – Shutdown 31

System – Log out USER... 31

Network – Network 31

Network – Notication 34

6DLR3-16N/XX

Table of contents

Devices – Camera 35

Devices – Audio 36

Devices – Alarm-Out 37

Devices – Display 38

Devices – Remote Control 39

Record – Record 40

Record – Schedule 41

Record – Pre-Event 42

Event – Alarm-In 43

Event – Motion Detection 45

Event – Video Loss 47

Event – Text-In 49

Event – System Event 52

Event – Event Status 54

Specications DLR3-16N/XX 55

Accessories 57

Supported PTZ cameras 58

Index 59

Notes on disposal 62

DLR3-16N/XX

Overview

Package contents

Digital video recorder (DVR)

Mains power cord

Operating instructions

RAS (Remote Administration System) software on CD

Operating instructions for RAS software on paper and CD

Mounting kit for cabinet installation

Basic functions

Record video images using multiple cameras

Even-based recording start

Video playback

Search for specic video sequences

Features

MPEG-4 compression / duplex mode

8 or 16 loop-through inputs / VGA, FBAS outputs

Audio and alarm inputs / outputs

Max. recording speed: 100 eld images per sec (PAL)

Memory capacity 160 GB / 410 GB / 660 GB

Maximum video resolution 720 x 576 pixels

Archiving/image transfer via USB and CD-RW

Live picture & Playback Zoom (2x)

Integral Motion Detector

Telemetry control functions via RS-485 port

Network connection (Ethernet)

Requirements for operation

Digital video recorder DLR3 connected

At least 1 camera connected

At least 1 monitor connected

Mouse connected, if DVR is to be controlled by mouse

Control options

Front panel

Mouse

RAS program

●

8DLR3-16N/XX

Connections on the rear

Note: Connections optionally for NTSC or PAL operation.

AUDIO IN 1 AUDIO IN 2 AUDIO OUT

VIDEO IN 1

LOOP1

VIDEO IN 2

LOOP2

VIDEO IN 3

LOOP3

VIDEO IN 4

LOOP4

VIDEO IN 5

LOOP5

VIDEO IN 6

LOOP6

VIDEO IN 7

LOOP7

VIDEO IN 8

LOOP8

VIDEO IN 9

LOOP9

VIDEO IN 10

LOOP10

VIDEO IN 11

LOOP11

VIDEO IN 12

LOOP12

VIDEO IN 13

LOOP13

VIDEO IN 14

LOOP14

VIDEO IN 15

LOOP15

VIDEO IN 16

LOOP16

SPOT

VIDEO OUT

NETWORK RS-232C VGA

NO C NO NC NO ARI GND /RX+

/RX-

TX+

TX-

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK,

CAUTION:

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

GND GND

AI9

AI11AI10 AI12 AI13 AI14 AI15 AI16

AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8

GNDGND

56 4 31315 9 7810111214

No. Designation Functions/connections Example devices

1 VIDEO IN 1-16 Max. 16 video channels Cameras

2 LOOP 1-16 Max. 16 loop-through video channels Cameras

3 AUDIO OUT Audio output Amplier, speakers

4AUDIO IN 1,

AUDIO IN 2 Max. 2 Audio inputs Microphone

5 SPOT Video output Spot monitor

6 VIDEO OUT Video output Monitor

7 VGA PC monitor PC monitor

8 RS-232C External interface Modem

9 NETWORK Network Network cable

10 AI1 - AI16 Alarm inputs for external devices Sensors

11 /RX+, /RX-,

TX+, TX- External interface (RS-485) Keyboard, PTZ camera

12 ARI/GND Reset alarm

with external signal Switch

13 NO, C, NC Alarm outputs for external devices Siren, ashing light

14 Reset switch Reset to factory defaults -

15 Power supply Mains power connection -

DLR3-16N/XX

Front panel controls

The following diagram and table set out the controls on the front panel of the DVR:

PANIC

DISPLAY GROUP MENU

SEQUENCE CAMEO

ALARM

CLIP COPY

SPOT

ZOOM PLAYBACK

PTZ

2 3 4 765

15 14 13 12 891011

No. Designation Function

1PTZ camera functions (secondary assignment)

SPOT, SEQUENCE,

CAMEO, DISPLAY,

GROUP, PTZ, ZOOM,

PLAYBACK, CLIP COPY

Function buttons

3 MENU Open/quit menu structure (primary assignment)

4 Menu navigation Navigate and select within the menu structure (secondary assignment)

5 Power-on indicator when DVR is in operation

6 Display at alarm

7 Indicates hard disk operation

8 Connections USB ports

9 Indicates recordings being copied

10 Indicates Ethernet or modem connection

11 Playback functions (primary assignment)

12 PANIC Start/end panic recording

13 ALARM Reset alarm

View event list

●

14 1 to 16 Select cameras

Enter passwords

●

15 Open built-in CD-RW writer

10 DLR3-16N/XX

Key to controls

Function buttons

Note: The secondary function assignment is accessed by holding down the key.

Element Function

Spot monitor assignments (secondary assignment)

Sequence On/Off (secondary assignment)

Cameo mode On/Off (secondary assignment)

Changing the image display modes (primary usage)

Switch displayed group (primary assignment)

PTZ camera functions On/Off (secondary assignment)

Zoom On/Off (primary assignment)

Start playback

Copying recordings

PTZ camera functions

Element Function

Zoom in

Close-up

Wide-angle

Save preset

Load preset

Playback functions

Element Function

Frame-by-frame rewind

Fast rewind

Start/pause playback

Fast forward

Frame-by-frame forward
