TruVision

Series 3 IP

Camera Installation

Guide

P/N 1073188-EN • REV E • ISS 22SEP17

Interlogix is part of UTC Climate, Controls & Security, a

unit of United Technologies Corporation. All rights

reserved.

Trademarks and

patents

Trade names used in this document may be trademarks

or registered trademarks of the manufacturers or

vendors of the respective products.

Manufacturer Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923,

USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

FCC compliance Class A: This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated in

a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

FCC conditions This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This Device must accept any interference received,

including interference that may cause undesired

operation.

ACMA compliance Notice! This is a Class A product. In a domestic

environment this product may cause radio interference

in which case the user may be required to take

adequate measures.

Canada This Class A digital apparatus complies with CAN

ICES-003 (A)/NMB-3 (A).

Cet appareil numérique de la classe A est conforme à

la norme CAN ICES-003 (A)/NMB-3 (A).

European Union

directives

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized European

standards listed under the EMC Directive 2014/30/EU,

the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with

this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon

the purchase of equivalent new equipment, or dispose

of it at designated collection points. For more

information see: www.recyclethis.info

2013/56/EU and 2006/66/EC (battery directive): This

product contains a battery that cannot be disposed of

as unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this symbol,

which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return

the battery to your supplier or to a designated collection

point. For more information see: www.recyclethis.info.

Contact information For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Installation Guide 1

Content

Introduction 1

Product overview 1

Installation 3

Installation environment 3

Package contents 4

Cable requirements 20

Camera description 20

Setting up the camera 28

Accessing the SD card 28

Mounting the IP fixed lens bullet camera 29

Mounting the IP VF lens bullet camera and the IP motorized

lens bullet camera (without the supplied back box) 30

Mounting the IP VF lens dome camera and IP motorized lens

dome camera 36

Mounting the IP fixed lens dome camera 41

Mounting the IP wedge dome camera 45

Mounting the IP turret camera 48

Using the camera with a recorder 53

Using the camera with TruVision Navigator 53

Specifications 54

TruVision IP fixed lens bullet cameras 54

TruVision IP VF lens bullet cameras 54

TruVision IP motorized lens bullet cameras 55

TruVision IP VF lens dome cameras 55

TruVision IP motorized lens dome cameras 56

2 Installation Guide

TruVision IP fixed lens dome 57

TruVision IP wedge cameras 57

TruVision IP turret cameras 58

Pin definitions 59

Installation Guide 1

Introduction

Product overview

This is the installation guide for TruVision Series 3 IP camera

models:

IP fixed lens bullet camera:

TVB-5301 (2MPX Bullet, 4 mm lens)

TVB-5302 (4MPX Bullet, 4 mm lens)

IP VF lens bullet camera:

TVB-5303 (2MPX Bullet, 2.8 to 12 mm VF lens)

TVB-5304(4MPX Bullet, 2.8 to 12 mm VF lens)

IP motorized lens bullet camera:

TVB-5305 (2MPX Bullet, 2.8-12 mm VF motorized lens)

TVB-5306 (4MPX Bullet, 2.8-12 mm VF motorized lens)

IP fixed lens dome camera:

TVD-5301 (2MPX Plastic Dome, 2.8 mm lens)

TVD-5302 (4MPX Plastic Dome, 2.8 mm lens)

IP VF lens dome camera:

TVD-5303 (2MPX VF Dome)

TVD-5304(4MPX VF Dome)

2 Installation Guide

IP motorized lens dome camera:

TVD-5305 (2MPX Dome, 2.8-12 mm VF Motorized lens)

TVD-5306 (4MPX Dome, 2.8-12 mm VF Motorized lens)

IP wedge camera:

TVW-5301 (2MPX Wedge, 2.0 mm lens, Gray)

TVW-5302 (2MPX Wedge, 2.8 mm lens, Gray)

TVW-5303 (2MPX Wedge, 2.8 mm lens, White)

TVW-5304 (2MPX Wedge, 2.8 mm lens, Black)

TVW-5305 (4MPX Wedge, 2.8 mm lens, Gray)

IP turret camera:

TVT-5301 (2MPX Turret, 2.8 mm lens, Gray)

TVT-5302 (2MPX Turret, 2.8 mm lens, White)

TVT-5303 (2MPX Turret, 2.8 mm lens, Black)

TVT-5304 (4MPX Turret, 2.8 mm lens, Gray)

TVT-5305 (4MPX Turret, 2.8 mm lens, White)

TVT-5306 (4MPX Turret, 2.8 mm lens, Black)

TVT-5307 (4MPX Turret, 4.0 mm lens, White)

Installation Guide 3

Installation

This section provides information on how to install the

cameras.

Installation environment

When installing your product, consider these factors:

•Electrical: Install electrical wiring carefully. It should be

done by qualified service personnel. Always use a proper

PoE switch or a 12 VDC UL listed Class 2 or CE certified

power supply to power the camera. Do not overload the

power cord or adapter.

•Ventilation: Ensure that the location planned for the

installation of the camera is well ventilated.

•Temperature: Do not operate the camera beyond the

specified temperature, humidity or power source ratings.

The operating temperature of the camera is between -30

to +60°C (-22 to 140°F). Humidity is below 90%.

•Moisture: Do not expose the camera to rain or moisture,

or try to operate it in wet areas. Turn the power off

immediately if the camera is wet and ask a qualified

service person for servicing. Moisture can damage the

camera and also create the danger of electric shock.

•Servicing: Do not attempt to service this camera

yourself. Any attempt to dismantle this product will

invalidate the warranty and may also result in serious

injury. Refer all servicing to qualified service personnel.

•Cleaning: Do not touch the sensor modules with fingers.

If cleaning is necessary, use a clean cloth with some

ethanol and wipe the camera gently. If the camera will not

4Installation Guide

be used for an extended period of time, put on the lens

cap to protect the sensors from dirt.

Package contents

Check the package and contents for visible damage. If any

components are damaged or missing, do not attempt to use

the unit; contact the supplier immediately. If the unit is

returned, it must be shipped back in its original packaging.

IP fixed lens bullet camera

Camera:

Drill template:

Screws:

Drywall anchor

7.5 × 24.5 mm (3 pcs)

Screw

M4 × 25 mm (3 pcs)

Drill Template

Screw hole All: for integrative bracket
