Kärcher MV 4 Premium Bedienungsanleitung

www.kaercher.com/register-and-win

59652880 05/14

MV 4 Premium

Δϳ

ΒήόϠ

English 5

11 12 13

15 16

– 5

Dear Customer,

Please read and comply with

these original instructions prior

to the initial operation of your appliance and

store them for later use or subsequent own-

ers.

In accordance with the descriptions and the

safety information in these operating in-

structions the appliance is intended for use

as a multi-purpose vacuum cleaner.

This appliance has been designed for use

in private households and is not intended

for commercial use.

–Protect the unit from rain. Do not store

outside.

–This device may not be used to suck in

ash and soot.

Use the multi-purpose vacuum cleaner only

with:

–Original filter bag.

–Original spare parts, accessories and

special accessories.

The manufacturer is not responsible for any

damages that may occur on account of im-

proper use or wrong operations.

The packaging material can be recy-

cled. Please do not place the packag-

ing into the ordinary refuse for dispos-

al, but arrange for the proper recy-

cling.

Old appliances contain valuable ma-

terials that can be recycled. Please

arrange for the proper recycling of old

appliances. Please dispose your old

appliances using appropriate collec-

tion systems.

Filters and filter bags are made from envi-

ronment-friendly materials.

They can therefore be disposed off through

the normal household garbage provided

you have not sucked in substances that are

not permitted to be thrown into household

garbage.

Notes about the ingredients (REACH)

You will find current information about the

ingredients at:

www.kaercher.com/REACH

Our KÄRCHER branch will be pleased to

help you further in the case of questions or

faults.

(See address on the reverse)

At the end of the operating instructions you

will find a selected list of spare parts that

are often required.

You can procure the spare parts and the at-

tachments from your dealer or your

KÄRCHER branch office.

The terms of the guarantee applicable in

each country have been published by our

respective national distributors. We will re-

pair possible faults on your unit free of

charge within the warranty period, insofar

as the faults are caused by material defects

or defective workmanship. Guarantee

claims should be addressed to your dealer

or the nearest authorized customer service

centre, and supported by documentary evi-

dence of purchase.

Contents

General notes. . . . . . . . . . . . . . EN . . .5

Safety instructions . . . . . . . . . . EN . . .6

Description of the Appliance. . . EN . . .7

Operation . . . . . . . . . . . . . . . . . EN . . .9

Maintenance and care . . . . . . . EN . .10

Troubleshooting . . . . . . . . . . . . EN . .10

Technical specifications . . . . . . EN . .10

General notes

Proper use

Environmental protection

Disposing the filters and filter bags

Customer Service

Ordering spare parts and special

attachments

Warranty

5EN

– 6

–This appliance is not intended

for use by persons with limit-

ed physical, sensory or men-

tal capacities or lacking expe-

rience and/or skills, unless

such persons are accompa-

nied and supervised by a per-

son in charge of their safety

or they have received precise

instructions on the use of this

appliance and have under-

stood the resulting risks.

–Children may only use this

appliance if they are over the

age of 8 and supervised by a

person in charge of their safe-

ty, or if they have received in-

structions on the use of this

appliance and have under-

stood the resulting risks.

–Children must not play with

this appliance.

–Supervise children to prevent

them from playing with the

appliance.

–Cleaning and user mainte-

nance must not be performed

by children without supervi-

sion.

–Keep packaging film away

from children - risk of suffoca-

tion!

–Switch the appliance off after

every use and prior to every

cleaning/maintenance proce-

dure.

–Risk of fire. Do not vacuum up

any burning or glowing ob-

jects.

–The appliance may not be

used in areas where a risk of

explosion is present.

몇Electrical connection

The appliance may only be con-

nected to alternating current.

The voltage must correspond

with the type plate on the appli-

ance.

Risk of electric shock

Never touch the mains plug and

the socket with wet hands.

Do not pull the plug from the

socket by pulling on the con-

necting cable.

Check the power cord with

mains plug for damage before

every use. If the power cord is

damaged, please arrange im-

mediately for the exchange by

an authorized customer service

or a skilled electrician.

To avoid accidents due to elec-

trical faults we recommend the

use of sockets with a line-side

current-limiting circuit breaker

(max. 30 mA nominal tripping

current).

Warning

Certain materials may produce

explosive vapours or mixtures

when agitated by the suction air!

Never vacuum up the following

materials:

–Explosive or combustible

gases, liquids and dust parti-

cles (reactive dust particles)

–Reactive metal dust particles

(such as aluminium, magne-

sium, zinc) in combination

Safety instructions

6 EN

– 7

with highly alkaline or acidic

detergents

–Undiluted, strong acids and

alkalies

–Organic solvents (such as

petrol, paint thinners, ace-

tone, heating oil).

In addition, these substances

may cause the appliance materi-

als to corrode.

Danger

Immediate danger that can

cause severe injury or even

death.

몇Warning

Possible hazardous situation

that could lead to severe injury

or even death.

Caution

Possible hazardous situation

that could lead to mild injury to

persons or damage to property.

Illustrations on fold-out page!

These operating instructions describe

the multi-purpose vacuum cleaners list-

ed on the front cover.

The illustrations show the maximum

equipment; depending on the model,

there are differences in equipment and

supplied accessories.

When unpacking the product, make sure

that no accessories are missing and that

none of the package contents have been

damaged. If you detect any transport dam-

ages please contact your dealer.

Illustration

To connect the suction hose during vac-

uuming.

Illustration

Position I: Appliance is switched on.

Position 0: Appliance is switched off

To carry the appliance or to remove the

appliance head after unlocking.

Illustration

In order to clean the filter, press the re-

lease key, fold out and remove the filter

box.

This accessory compartment allows the

storage of suction nozzles and the power

cable.

Symbols in the operating

instructions

Description of the Appliance

Suction hose connection

ON/OFF switch for appliance

Carrying handle

Filter box and release key

Accessory compartment, hook

7EN

– 8

Illustration

To rest the floor nozzle during work in-

terruptions.

Illustration

Pull out to open, push in to lock.

Illustration

This accessory compartment allows the

storage of the suction pipes or other ac-

cessories.

Illustration

Turn the container, press in the steering

roller in the openings at the base of the

container till the end-point.

Note: Do not use a filter bag for wet vacu-

uming!

Illustration

Recommendation: To vacuum fine

dust, use the filter bag.

Caution

Always work with an inserted flat

fold filter - during wet as well as

dry vacuum cleaning!

Illustration

Push the suction hose into the connec-

tion on the appliance, it snaps in place.

In order to disconnect it, push down

with your thumb and pull the suction

hose out.

Note: Accessories, such as suction brush-

es (optional) can be directly attached to the

connecting piece and thus connected to the

suction hose.

For convenient working even in tight spac-

es.

The removable handle can be attached be-

tween the accessories and the suction

hose if necessary.

See position 13.

Recommendation: In order to vacuum the

floor, attach the handle to the suction hose.

Illustration

Connect the handle with the suction

hose until it snaps in place.

Illustration

To remove the handle from the suction

hose, press the notch using your thumb

and pull off the handle.

Note: Due to removing the handle, acces-

sories can be directly attached to the suc-

tion hose.

See position 12.

Recommendation: In order to vacuum the

floor, attach the handle to the suction hose.

Illustration

Put both suction pipes together and

connect them with the handle.

When vacuuming dry dirt off the floor,

clip an insert with two brush strips into

the floor nozzle.

When vacuuming water off the floor,

clip an insert with two rubber lips into

the floor nozzle.

Parking position

Container closure

Accessory storage container

Steering roller

Filter bag

Flat fold filter

(already installed in the appliance)

Suction hose with connecting

piece

Removable handle

suction pipes 2 x 0.5 m

Floor nozzle

(with inserts)

8 EN

– 9

For edges, joints, heaters and hard to

reach locations.

Caution

Always work with an inserted flat

fold filter - during wet as well as

dry vacuum cleaning!

Illustration

Remove the appliance head.

Turn the container, press in the steering

roller in the openings at the base of the

container till the end-point.

Insert and lock the appliance head.

Illustration

Connect accessories.

Illustration

Plug in the main plug.

Illustration

Turn on the machine.

Caution

Work with a dry flat fold filter on-

ly.

Check the filter for damage prior

to installation and replace as

necessary.

Illustration

Recommendation: To vacuum fine

dust, use the filter bag.

–The filling level of the filter bag depends

on the dirt that is sucked in.

–The filter bag needs to be replaced

more frequently while sucking in fine

dust, sand, etc.

–Clogged filter bags can burst - therefore

make sure to replace the filter bag in a

timely manner!

Caution

Vacuum cold ashes only when

using a pre-filter.

Order no. basic design: 2.863-139.0, pre-

mium design: 2.863-161.0.

For vacuuming up moisture or wetness

pay attention to the correct floor nozzle

insert and connect the corresponding

accessories.

몇Warning

Immediately switch the appli-

ance off or pull the power plug if

foam forms or liquids escape!

Do not use a filter bag!

Note: If the container is full, a float closes

the suction opening, and the appliance

works at a higher speed. Switch off the ap-

pliance immediately, and empty the con-

tainer.

Illustration

Turn off the appliance.

Illustration

Hook the floor nozzle into the parking

position.

Turn off the appliance and disconnect

the mains plug.

Illustration

Remove the appliance head and empty

the reservoir filled with wet or dry dirt.

Illustration

Store the accessories and the mains

cable on the appliance and store the

appliance in dry rooms.

Crevice nozzle

Operation

Before Startup

Start up

Dry vacuum cleaning

Information filter bag

Wet vacuum cleaning

Interrupting operation

Finish operation

Empty the container

Storing the appliance

9EN

– 10

Danger

Turn off the appliance and re-

move the mains plug prior to any

care and maintenance work.

Repair works may only be per-

formed by the authorised cus-

tomer service.

몇Warning

Do not use abrasives, glass or

universal cleaners! Never im-

merse the appliance in water.

Clean the appliance and accessory

parts made of plastic with a commercial

plastic cleaner.

If required, rinse the container and ac-

cessories with water properly and dry

them before reuse.

Recommendation: Clean the filter box

after every use.

Illustration

Unlock, fold out and remove the filter

cartridge, empty dirt from the filter car-

tridge over a waste bin.

In order to clean the inserted flat fold fil-

ter, knock the filter box against the edge

of the waste bin. It is not necessary to

remove the flat fold filter from the filter

box.

If necessary, clean the flat fold filter sep-

arately.

Illustration

Unlock, fold out and remove the filter

cartridge.

Illustration

Remove the flat fold filter from the filter

box and tab it out.

When necessary, clean under running

water only, do not wipe or brush down.

Allow to dry completely prior to use.

Finally, reinstall the dry flat fold filter into

the appliance. Insert the filter cartridge

into the appliance.

If the suction power becomes less, check

the following points:

Accessories, suction hose or suction

pipes are clogged, please remove the

obstruction using a stick.

Illustration

Filter bag is full: Insert new filter bag.

Illustration

Flat fold filter contaminated: Remove

the filter box and clean filter (see Chap-

ter "Cleaning the flat fold filter").

Replace damaged flat fold filter.

Subject to technical modifications!

Maintenance and care

Clean flat fold filter

Troubleshooting

Decreasing cleaning power

Technical specifications

Voltage

1~50/60 Hz

220 -

240

Output Pnom 1000 W

Mains fuse (slow-blow) 13 A

Container capacity 20 l

Water intake with handle 12 l

Water intake with floor

nozzle

10 l

Power cord H05VV-F

2x0,75

Sound pressure level

(EN 60704-2-1)

72 dB(A)

Weight (without acces-

sories)

7,6 kg

10 EN

Andere Handbücher für MV 4 Premium

Inhaltsverzeichnis

Sprachen:

Andere Kärcher Staubsauger Handbücher

Kärcher

Kärcher SG 4/4 Bedienungsanleitung

Kärcher

Kärcher NT 35/1 Tact Bedienungsanleitung

Kärcher

Kärcher NT 27/1 Bedienungsanleitung

Kärcher

Kärcher NT 561 Eco Package Craftsmen Bedienungsanleitung

Kärcher

Kärcher NT 361 ECO M A Bedienungsanleitung

Kärcher

Kärcher SC 5 Iron Plug Bedienungsanleitung

Kärcher

Kärcher WV 50 Plus Bedienungsanleitung

Kärcher

Kärcher T 7/1 Classic Bedienungsanleitung

Kärcher

Kärcher A 2204 Bedienungsanleitung

Kärcher

Kärcher PUZZI 300 Bedienungsanleitung

Kärcher

Kärcher NT 55/1 Eco Bedienungsanleitung

Kärcher

Kärcher WD 3 Premium Bedienungsanleitung

Kärcher

Kärcher SC 5.800 C Bedienungsanleitung

Kärcher

Kärcher SE 3001 plus Bedienungsanleitung

Kärcher

Kärcher NT 361 ECO M A Bedienungsanleitung

Kärcher

Kärcher CV 38/2 Bedienungsanleitung

Kärcher

Kärcher A 2656 X plus Bedienungsanleitung

Kärcher

Kärcher KM 75/40 W Bp Bedienungsanleitung

Kärcher

Kärcher IVC 60/24-2 Ap Bedienungsanleitung

Kärcher

Kärcher NT 48/1 Bedienungsanleitung

Kärcher

Kärcher SE 5.100 Bedienungsanleitung

Kärcher

Kärcher BRC 46/38 C Bedienungsanleitung

Kärcher

Kärcher SC 1.020 Bedienungsanleitung

Kärcher

Kärcher NT 50/1 Me Classic Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
