Kärcher WD 4 Bedienungsanleitung

English. . . . . . . . . 2

Español. . . . . . . . 18

Français. . . . . . . 36

59656210 (07/15)

WD 4

2 English

DANGER

Pointer to immediate danger, which

leads to severe injuries or death.

몇WARNING

Pointer to a possibly dangerous situa-

tion, which can lead to severe injuries

or death.

몇CAUTION

Pointer to a possibly dangerous situa-

tion, which can lead to minor injuries.

ATTENTION

Pointer to a possibly dangerous situa-

tion, which can lead to property dam-

age.

Subject to technical modifications!

MULTI-PURPOSE VACUUM CLEANER OPERATOR MANUAL

MULTI-PURPOSE VACUUM

CLEANER OPERATOR MANU-

AL . . . . . . . . . . . . . . . . . . . . . . 2

IMPORTANT SAFETY IN-

STRUCTIONS . . . . . . . . . . . . 4

READ ALL INSTUCTIONS BE-

FORE USING THIS APPLIANCE 4

SAVE THESE INSTRUCTIONS 5

MODEL OVERVIEW . . . . . . . 6

OPERATING INSTRUCTIONS 8

USING THE ACCESSORIES. 13

CARE AND MAINTENANCE IN-

STRUCTIONS . . . . . . . . . . . . 14

TROUBLESHOOTING . . . . . . 17

Safety Alert Symbols

Specifications

Voltage

~60 Hz

120 V

Power consumption 9 A

Container capacity 5,3

(20)

gal

(l)

Water intake with han-

dle

3,4

(13)

gal

(l)

Water intake with floor

nozzle

2,9

(11)

gal

(l)

Power cord 2xAWG16SJTW

Sound pressure level

(EN 60704-2-1)

74 dB(A)

Weight (without ac-

cessories)

16,3

(7,4)

lbs

(kg)

Part No. 1.348-115.0

English 3

In accordance with the descriptions

and the safety information in these op-

erating instructions the appliance is in-

tended for use as a multi-purpose vac-

uum cleaner.

This appliance has been designed for

use in private households and is not in-

tended for commercial use.

–Use indoors only.

–This device may not be used to

suck in ash and soot.

Use the multi-purpose vacuum cleaner

only with:

–Original filter bag.

–Original spare parts, accessories

and special accessories.

The manufacturer is not responsible

for any damages that may occur on ac-

count of improper use or wrong opera-

tions.

The owner and/or user must have an

understanding of the manufacturer’s

operating instructions and warnings

before using this appliance.

Warning information should be empha-

sized and understood.

If the operator is not fluent in English,

the manufacturer’s instructions and

warnings shall be read to and dis-

cussed with the operator in the opera-

tor’s native language by the purchaser/

owner, making sure that the operator

comprehends its contents.

Owner and/or user must study and

maintain for future reference the man-

ufacturers’ instructions.

The scope of delivery of your appliance

is illustrated on the packaging. Check

the contents of the appliance for com-

pleteness when unpacking.

In the event of missing accessories or

any transport damage, please contact

your dealer.

To register this product, please visit:

www.karcher-register.com

For technical support, go to:

www.karcher-help.com

If you need to file a warranty claim,

please call: 1-800-537-4129

You will need to fax or email your re-

ceipt to a customer service agent. All

other information can be found at:

www.karcherresidential.com

Call: 01-800-024-13-13 for help or visit

our website: www.karcher.com.mx

Proper use

Owner/User Responsibility

Scope of delivery

Customer Support

USA and Canada

Customer Support Mexico

4 English

When using this product basic precau-

tions should always be followed, in-

cluding the following:

For household use only!

몇WARNING

To reduce the risk of fire, electric

shock, or injury:

–DO NOT LEAVE appliance unat-

tended when plugged in. Unplug

from outlet when not in use and be-

fore servicing.

–Use indoors only.

–Do not allow to be used as a toy.

Close attention is necessary when

used by or near children.

–Use only as described in this manu-

al. Use only manufacturer’s recom-

mended attachments.

–Do not use with damaged cord or

plug. If appliance is not working as

it should, has been dropped, dam-

aged, left outdoors, or dropped into

water, return it to a service center.

–Do not pull or carry by the cord, do

not use cord as a handle, do not

close a door on the cord, or pull

cord around sharp edges or cor-

ners. Do not run appliance over

cord. Keep cord away from heated

surfaces.

–Do not unplug by pulling cord. To

unplug, grasp plug.

–Never touch the mains plug with

wet hands.

–Use extra care when cleaning on

stairs.

–Turn off all controls before unplug-

ging.

–Never immerse the appliance in

water or other liquids.

–The appliance must be level and on

the floor during use.

–The appliance may not be operated

in explosive atmospheres.

–Do not service the appliance when

it is plugged in.

–Do not put any objects into open-

ings. Do not use if openings are

blocked; keep free of dust, lint, hair,

and anything that may reduce air

flow.

–Do not use to pick up flammable or

combustible liquids, such as gaso-

line, or use in areas where they may

be present.

–Do not pick up anything that is burn-

ing or smoking such as cigarettes,

matches or hot material.

–Keep hair, loose clothing, fingers,

and all parts of the body away from

openings and moving parts.

–Do not vacuum near toxic or health

endangering materials such as as-

bestos, pesticides, fertilizers, or an-

ything that is poisonous.

–Do not vacuum explosive dusts or

use cleaner in areas that may con-

tain explosive substances such as

coal, grain, or any other fine, com-

bustible material.

–Avoid picking up hard, sharp ob-

jects with the cleaner. They may

damage the cleaner and the filter.

IMPORTANT SAFETY INSTRUCTIONS

READ ALL

INSTUCTIONS

BEFORE USING

THIS APPLIANCE

English 5

–Do not use without filter and/or dust

bag in proper place.

SAVE THESE

INSTRUCTIONS

6 English

MODEL OVERVIEW

1 Suction hose connection

2 ON/OFF switch for appliance

3 Carrying handle

4 Filter box and release key

5 Accessory compartment, hook

6 Parking position

7 Container closure

8 Accessory storage container

9 Steering roller

English 7

Accessories

10 Filter bag

11 Flat fold filter

12 Suction hose with connecting piece

13 Removable handle

14 Suction tubes 2 x 0.5 m

15 Floor nozzle

(with inserts)

16 Crevice nozzle

11 12

13 15

8 English

Release and remove the appliance

head.

Turn the container, press in the

steering roller in the openings at the

base of the container till the end-

point.

Insert and lock the appliance head.

Push the suction hose into the con-

nection on the appliance, it snaps in

place.

OPERATING INSTRUCTIONS

ASSEMBLY INSTRUCTIONS

English 9

Connect the handle with the suction

hose until it snaps in place.

Put both suction tubes together and

connect them with the handle.

Connect the floor nozzle with the

suction tubes.

When vacuuming dry dirt off the

floor, clip an insert with two brush

strips into the floor nozzle.

When vacuuming water off the

floor, clip an insert with two rubber

lips into the floor nozzle.

10 English

ATTENTION

Work with a dry flat fold filter only.

Check the filter for damage prior to in-

stallation and replace as necessary.

Vacuum cold ashes only when using a

pre-filter.

Order no. basic design: 2.863-139.0,

premium design: 2.863-161.0.

Recommendation: To vacuum fine

dust, use the filter bag.

몇WARNING

Immediately switch the appliance off or

pull the power plug if foam forms or liq-

uids escape!

Note: Do not use a filter bag for wet

vacuuming!

Note: If the container is full, a float

closes the suction opening, and the ap-

pliance works at a higher speed.

Switch off the appliance immediately,

and empty the container.

For vacuuming up moisture or wet-

ness pay attention to the correct

floor nozzle insert and connect the

corresponding accessories.

Dry vacuum cleaning Wet vacuum cleaning
