INSTALLATION INSTRUCTIONS FOR PART 99-8218

Phillips Screwdriver •Socket

1-800-221-0932 www.metraonline.com

KIT FEATURES

•DIN Radio Provision with Pocket

•ISO Radio Provision with Pocket

•Double DIN Radio Provision

•Stacked ISO Units Provision

99-8218

APPLICATIONS

A) Radio Housing •B) Radio Housing Brackets •C) ISO Snap-In Brackets •D) Double DIN Brackets

KIT COMPONENTS

E) Trim Plate •F) Double DIN Trim Plate •G) Pocket •H) (4) # 8 x 3/8 Phillips Screws •I) (4) #4 x 1/4 Phillips Screws

Small Flat Blade Screwdriver or

Panel Removal Tool

TOYOTA

CAMRY / CAMRY HYBRID

2007-2011

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Wire harness:

•70-1761 Toyota 1987-up

•TYTO-01 Toyota amp interface harness 2003-up

Antenna adapter:

•Not required

TOOLS REQUIRED:

Dash Disassembly

- Toyota Camry / Camry Hybrid 2007-2011 . . . . . . . . . . . . 1, 2

Kit Assembly

- DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . 3

- ISO Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . 4

- Double DIN Radio Provision . . . . . . . . . . . . . . . . . . . . . . . . . . 5

- Stacked ISO Units Provision . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Final Assembly ....................................7

TABLE OF CONTENTS

99-8218

NOWLEDGE IS

OWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take

steps toward a better tomorrow.

99-8218 DASH DISASSEMBLY

TOYOTA CAMRY/CAMRY HYBRID 2007-2011

Disconnect the negative battery terminal

to prevent an accidental short circuit.

Turn the shift knob counterclockwise to

remove.

Unclip and remove (1) trim panel from each

side of the pocket below the radio/climate

control assembly. (2 panels total)

(Figure A)

Unclip and remove the top of the center

console including the cup holders.

(Figure B)

123456

Continued on Page 2.

Unclip and remove the shift knob trim

panel. (Figure B)

Remove (1) Phillips screw from each

side of pocket below the radio/climate

control assembly (2 screws total).

(Figure C)

Unclip and remove the pocket.

(Figure C)

99-8218 DASH DISASSEMBLY

10 Remove the (10) Phillips screws securing

the brackets to the radio/climate control

assembly and separate the radio from the

climate controls. (Retain climate controls

and screws for use during kit assembly).

(Figure C)

123456

Unclip and remove the A/C vents above

the radio. (Take care not to scratch the

dash panel. (Figure A)

Remove (2) 10mm bolts above the radio

(behind the A/C vents) and (2) 10mm

bolts below the climate controls (behind

pocket) then unplug and remove the

radio/climate control assembly.

(Figure B)

Unscrew and remove the (2) Clips from

the back of the factory radio. (Retain clips

for use during kit assembly. (Figure C)

Continue to kit assemby.

TOYOTA CAMRY / CAMRY HYBRID 2007-2011

99-8218 KIT ASSEMBLY

DIN RADIO PROVISION WITH POCKET

1Slide the DIN cage into the Radio

Housing and secure by bending

the metal locking tabs down.

(

Figure A)

2Slide the after-market radio into the

cage until it snaps into place.

(

Figure B)

3Snap the pocket into the radio

housing. (

Figure B)

NOTE: Refer also to the instructions

included with the aftermarket radio.

Continue to Final Assembly.

4Align the small legs on the bottom

of the radio housing with the slots in

the top of the climate control. Then

slide the climate control sideways to

engage together. (

Figure C)

5Attach the radio housing brackets to

the radio housing using the included

Phillips screws. (

Figure D)

6Secure the radio housing brackets to

the climate control using the factory

hardware. (

Figure D)

7Attach the (2) clips removed in step

11 in dash disassembly to the radio

housing brackets using the supplied

small Phillips screws.(

Figure D)

99-8218

KIT ASSEMBLY

1Mount the ISO Brackets to the

radio with the screws supplied

with the radio. (

Figure A)

2Slide the radio into the radio open-

ing until the side clips engage.

(

Figure B)

4Snap the pocket into the radio

housing. (

Figure B)

NOTE: Refer also to the instructions

included with the aftermarket radio.

Continue to Final Assembly.

5Align the small legs on the bottom

of the radio housing with the slots in

the top of the climate control. Then

slide the climate control sideways to

engage together. (

Figure C)

6Attach the radio housing brackets to

the radio housing using the included

Phillips screws. (

Figure D)

7Secure the radio housing brackets to

the climate control using the factory

hardware. (

Figure D)

8Attach the (2) clips removed in step

11 in dash disassembly to the radio

housing brackets using the supplied

small Phillips screws.(

Figure D)

ISO RADIO PROVISION WITH POCKET

3Snap the Trim plate into the Radio

Housing. (

Figure B)

99-8218

KIT ASSEMBLY

1Cut and remove center divider

from radio housing. (

Figure A)

2Snap the Double DIN brackets to the

inside edge of the radio housing.

(

Figure B)

3Slide the Double DIN radio into the

Double DIN bracket/radio housing

assembly and secure the radio to the

assembly using the screws supplied

with the radio. (

Figure C)

NOTE: Refer also to the instructions

included with the aftermarket radio.

Continue to Final Assembly.

4Snapthe Double DIN trim-plate into

the housing/radio assembly. (

Figure C)

5Align the small legs on the bottom of

the radio housing with the slots in the

top of the climate control then slide the

climate control sideways to engage

together. (

Figure D)

6Attach the corresponding radio housing

bracket to the radio housing using the

included Phillips screws. (

Figure E)

8Attach the (2) clips removed in step 11 in

dash disassembly to the radio housing

brackets using the supplied small Phillips

screws.(

Figure E)

DOUBLE DIN

7Secure the radio housing brackets to

the climate control using the factory

hardware. (

Figure E)

RADIO PROVISION

99-8218

KIT ASSEMBLY

1Cut and remove center divider

from radio housing. (

Figure A)

2Snap the Double DIN brackets to the

inside edge of the radio housing.

(

Figure B)

3Slide the Stacked ISO units into the

Double DIN bracket/radio housing

assembly and secure the radio to the

assembly using the screws supplied

with the units. (

Figure C)

NOTE: Refer also to the instructions

included with the aftermarket radio.

Continue to Final Assembly.

4Snapthe Double DIN trim-plate into

the housing/radio assembly. (

Figure C)

5Align the small legs on the bottom of

the radio housing with the slots in the

top of the climate control then slide the

climate control sideways to engage

together. (

Figure D)

6Attach the corresponding radio housing

bracket to the radio housing using the

included Phillips screws. (

Figure E)

8Attach the (2) clips removed in step 11

in dash disassembly to the radio housing

brackets using the supplied small

Phillips screws.(

Figure E)

STACKED ISO

7Secure the radio housing brackets to

the climate control using the factory

hardware. (

Figure E)

UNITS PROVISION

99-8218

FINAL ASSEMBLY

Locate the factory wiring harness in the dash. Metra recommends using the

proper mating adapter and making connections as shown.

(Isolate and individually tape off the ends of any unused wires to prevent

electrical short circuit.)

Re-connect the negative battery terminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Make wiring connections using the EIA color code chart shown belowand the instructions included with the head

unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually

tape off ends of any unused wires to prevent electrical short circuit.

12V Ignition / Acc . . . Red

12V Batt / Memory . . Yellow

Ground . . . . . . . . . . . Black*

Power Antenna . . . . . Blue

Amp Turn-On . . . . . . Blue / White

Amp Ground . . . . . . . Black / White

Illumination. . . . . . . . Orange

Dimmer . . . . . . . . . . Orange / White

Right Front (+) . . . . . White

Left Front (-) . . . . . . . White / Black

Right Rear (+). . . . . . Violet

Right Rear (-) . . . . . . Violet / Black

Left Rear (+). . . . . . . Green

Left Rear (-) . . . . . . . Green / Black

*NOTE: When Black a wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’s specifications.

METRA / EIA WIRING CODE

FINAL WIRING CONNECTIONS

99-8218

NOTES
