INSTALLATION INSTRUCTIONS FOR PART 99-8211

Small Flat Blade Screwdriver I Phillips Screwdriver I Socket Wrench

1-800-221-0932 www.metraonline.com

KIT FEATURES

APPLICATIONS

2000-04 TOYOTA AVALON

• DIN Head Unit Provisions with Pocket

• ISO DIN Head Unit Provisions with Pocket

A) Radio Housing I B) ISO Brackets I C) ISO Trim Plate I D) Radio Housing Brackets

KIT COMPONENTS

TOOLS REQUIRED:

99-8211

•

Dash Disassembly

- 2000-2004 Toyota Avalon (column shift models) . . . . . . . . . . . 1

- 2000-2004 Toyota Avalon (console shift models) . . . . . . . . . . 2

•

Kit Assembly

- DIN Head Unit Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

- ISO DIN Head Unit Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

•

Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

- Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 & 7

TABLE OF CONTENTS

99-8211

DASH DISASSEMBLY

2000-2004 TOYOTA AVALON (column shift models)

Disconnect the negative battery terminal

to prevent an accidental short circuit.

Unsnap the trim below the climate

control to reveal (2) 10 MM bolts

and remove.

(Figure A)

Carefully pull air vents above radio

towards rear of car to unsnap. Note:

There are (3) snaps, (2) are at the bottom

sides and (1) is at the top middle of the

vent assembly.

(Figure B)

Remove (2) 10 MM bolts from above

radio/climate control assembly and

remove assembly together.

(Figure C)

Remove (6) Phillips screws (4 from radio

and 2 from climate control) from each

side bracket to separate radio and cli-

mate control.

(Figure D)

99-8211

DASH DISASSEMBLY

2000-2004 TOYOTA AVALON (console shift models)

Disconnect the negative battery terminal

to prevent an accidental short circuit.

Open the center console armrest,

unsnap cover above cup holder and

remove (2) Phillips screws toward

the outside of the panel.

(Figure A)

Carefully pull air vents above radio

towards rear of car to unsnap. Note:

There are (3) snaps, (2) are at the bottom

sides and (1) is at the top middle of the

vent assembly.

(Figure D)

Remove (2) 10 MM bolts from above

radio/climate control assembly and

remove assembly together.

(Figure E)

Remove (6) Phillips screws (4 from radio

and 2 from climate control) from each

side bracket to separate radio and cli-

mate control.

(Figure F)

E F

Lift up and remove shifter trim/ashtray

assembly.

(Figure B)

Unsnap black cover from under climate

controls and remove (2) 10 MM bolts.

(Figure C)

99-8211

KIT ASSEMBLY

DIN Head Unit Provision

Slide the mounting bracket

onto the 99-8211 until side

clips engage.

(Figure A)

Slide factory climate controls

into the 99-8211 and secure

using the factory hardware.

(Figure B)

Slide the DIN cage into the Radio

Housing and secure by bending the

metal locking tabs down.

(Figure C)

Slide the aftermarket head unit

into the cage and secure.

Snap the Trim plate into the

Radio Housing.

99-8211

KIT ASSEMBLY

ISO DIN HEAD UNIT PROVISION

Slide the mounting bracket onto

the 99-8211 until side clips

engage.

(Figure A)

Slide factory climate controls

into the 99-8211 and secure

using the factory hardware.

(Figure B)

Mount the ISO Brackets to the

head unit with the screws sup-

plied with the unit.

Slide the head unit into the radio

opening until the side clips

engage.

(Figure C)

Snap the Trim plate into the

Radio Housing.

99-8211

FINAL ASSEMBLY

Locate the factory wiring harness in the dash.

Metra recommends using the proper mating

adapter and making the connections as shown.

(Isolate and individually tape off the ends of

any unused wires to prevent electrical short

circuit)

Re-connect the negative battery terminal and test

the unit for proper operation.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Reassemble radio and dash assemblies in

reverse order of disassembly.

NOTES

99-8211

NOTES

99-8211

1-800-221-0932 www.metraonline.com

INST998211
