Midea MVC-I5C Bedienungsanleitung

ROBOT Vacuum

Cleaner

INSTRUCTION MANUAL

i5C

PLEASE READ THE

MANUAL CAREFULLY

BEFORE USING AND

KEEP IT PROPERLY FOR

FUTURE USE

www.midea.com

i5C

01 22

Technical data

01 02

SAFETY INSTRUCTIONS

Warning for the machine

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made

by children without supervision.

Plug must be removed from the socket-outlet

before cleaning or maintaining the appliance.

appliance.

If the supply cord is damaged, it must be replaced

by a special cord or assembly available from the

manufacturer or its service agent.

WARNING: For the purposes of recharging the

battery,

only use the detachable docking station provided

with this appliance.

Use only with i5-DS docking station.

This appliance contains batteries that are only

replaceable by skilled persons.

Do not bring the smart robot close to heatsource,

radiation or burning cigarette butts. It is strictly

forbidden to vacuum the following objects:

1)All liquids such as water and solvents;

2)Lime, cement dust and other construction dust

and garbage;

3)Heat generating objects, such as unextinguished

carbon butts, cigarette butts;

4)Sharp fragments, such as glass, etc.;

5)Flammable and explosive items, such as

gasoline and alcohol products.

Before using, please remove all fragile items from

the ground (such as glasses, lamps, etc.), and

items that may be tangled with the side brush,

Roller brush and drive wheels(such as wires,

curtains and other easily-entangled materials).

Please pay attention to your hair and avoid

entanglement on wheels or roller brushes when

using, cleaning and maintaining the robot.

Do not use this product at an altitude of more

than 2000m.

Correct Disposal of this product.

This marking indicates that this product should

not be disposed with other household wastes

throughout the EU. To prevent possible harm to

the environment or human health from

uncontrolled waste disposal, recycle it responsibly

to promote the sustainable reuse of material

resources. To return your used device, please use

the return and collection systems or contact the

retailer where the product was purchased. They

can take this product for environmental safe

recycling.

Warranty Information

The manufacturer provides warranty in

accordance with the legislation of the customer's

own country of residence, with a minimum of 1

year (Germany: 2 years), starting from the date on

which the appliance is sold to the end user.

The warranty only covers defects in material or

workmanship.

The repairs under warranty may only be carried

out by an authorized service centre. When making

a claim under the warranty, the original bill of

purchase (with purchase date) must be submitted.

The warranty will not apply in cases of:

- Normal wear and tear

10.

11.

- Incorrect use, e.g. overloading of the appliance,

use of non-approved accessories

- Use of force, damage caused by external

inﬂuences

- Damage caused by non-observance of the user

manual, e.g. connection to an unsuitable mains

supply or non-compliance with the installation

instructions

- Partially or completely dismantled appliances

WIFI:2400-2483.5MHz, MAX POWRE:20dBm.

To satisfy RF exposure requirements, a separation

distance of 20 cm or more should be maintained

between the antenna of this device and persons

during device operation.To ensure compliance,

operations at closer than this distance is not

recommended.

12.

03 04

05 06

Warning for docking station

“IMPORTANT SAFETY INSTRUCTIONS – SAVE

THESE INSTRUCTIONS" and "DANGER – TO

REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS".

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made

by children without supervision.

Plug must be removed from the socket-outlet

before cleaning or maintaining the appliance.

appliance.

If the supply cord is damaged, it must be replaced

by a special cord or assembly available from the

manufacturer or its service agent.

Docking base is only applicable to the product

i5C. (Battery pack type: Li-ion, DC 14.4 V, 2600

mAh)

The Docking base will automatically start charging

after Robot Vacuum Cleaner returned to the base.

Warning for battery

10.

11.

the battery.

Please note that do not disassemble the battery by

yourself.

If you need to replace it, please contact the

after-sales service center.

Please dispose of used battery according to local

laws and regulations.

Do not dismantle, open or shred the battery.

Do not expose batteries to heat or ﬁre. Avoid storage

in direct sunlight.

Do not short-circuit a battery.

Do not store batteries haphazardly in a box or drawer

where they may short-circuit each other or be

short-circuited by other metal objects.

Do not subject batteries to mechanical shock.

In the event of a leaking, do not allow the liquid to

come in contact with the skin or eyes. If contact has

amounts of water and seek medical advice.

Do not use any charger other than that speciﬁcally

provided for use with the equipment.

Warning: The battery charger(Docking station)

is not intended to charge non-rechargeable

batteries.

07 08

16.

17.

18.

19.

20.

21.

Keep batteries clean and dry.

Do not leave a battery on prolonged charge when

not in use.

After extended periods of storage, it may be

necessary to charge and discharge the batteries

several times to obtain maximum performance.

The batteries give their best performance when

they are operated at normal room temperature

(20 °C ± 5 °C).

Retain the original product literature for future

reference.

The battery may be irreversibly damaged if the

battery is in low power for a long time. It is

power before storage.

12.

13.

14.

15.

Do not use any battery which is not designed for use

with the equipment.

type within a device.

Keep batteries out of the reach of children.

Seek medical advice immediately if the battery has

been swallowed.

[symbol IEC 60417-5957

( 2004-12 )]

[symbol ISO 7000-0790

( 2004-01 )]

[symbol IEC 60417-5031

( 2002-10 )]

[symbol IEC 60417-5032

( 2002-10 )]

[symbol IEC 60417-5172

( 2003-02 )]

time-lag miniature fuse-link where X is the symbol for the

time/current characteriﬆic as given in IEC 60127

for indoor use only

read operator's manual

direct current

alternating current

class II equipment

09 10

TECHNICAL DATA

Product Model: i5C

Host Charging Voltage: 17.2 V

Host Rated Voltage:14.4 V

Host Rated Power:55 W

Docking Station Model:i5-DS

Docking Station Input:100-240V~,50/60Hz,24W

Docking Station Output:17.2V ,1A

Battery Model:BP14426E

Battery Rated Voltage:14.4V

Battery Capacity:2600mAh 37.44Wh

Charging Limit Voltage:16.8V

10.

11.

Note: you can also view the instructions on the app.

Midea Robozone Technology Co.,Ltd

Add.: No.39 Caohu Avenue, Xiangcheng

Economic Development Zone,Suzhou, Jiangsu, China

11 12
