1 Startup Manual

STARTUP MANUAL

PCI-1671UP High-Performance GPIB PCI Interface Card

USB-4671 High-Performance GPIB USB Interface Module

Your interface board consists of hardware and soft-

ware that fully implement the IEEE 488 standard,

also known as GPIB. This document enables you to

install, configure, test, and verify your installation.

Other documentation, including the GPIB Program-

ming Reference Manual, is available in the root

directory on your software CD in Adobe Portable

Document Format (PDF). To view these PDF files,

you must have Adobe Acrobat Reader version 4.0 or

later installed on your system. If you do not have

this program, refer to the Adobe Systems Incorpo-

rated Web site, http://www.adobe.com/products/

acrobat/readstep2.html, to download the Acrobat

Reader program. There is no charge for this down-

load.

Program and documentation copyrighted 2005 by

Advantech Co., Ltd. The software interpreter contained in

EPROM/ROM is copyrighted and all rights are reserved by

Advantech Co., Ltd. Copying or duplicating this product is

a violation of law.

Application software libraries provided on disk are copy-

righted by Advantech Co., Ltd. The purchaser is granted the

right to include portions of this software in products which

use one of the IEEE 488 interface boards (including those

sold through resellers). The software may not be distributed

other than for the application just mentioned.

No part of this document may be reproduced or transmitted

in any form or by any means, electronic, optical, or mechan-

ical, including photocopying and recording, or by any infor-

mation storage and retrieval system, without permission in

writing from Advantech Co., Ltd.

Follow these steps to install the software:

The installer should start automatically when you

insert the CD supplied with the interface card into

the drive. If it does not, explore the CD drive and

double-click setup.exe in the:

CD\Drivers\GPIB\ PCI-1671 directory to start the

installer. You can also start the installer by selecting

Start>Run and choosing setup.exe from the CD

directory.

Please Note that NI-488.2 driver must be

removed before running "setup.exe" to avoid

confliction.

Proceed through the installer screens by clicking the

Next button until you see the Select Features win-

dow, where you can choose the features to install.

Click on each feature for a brief description. All fea-

tures are installed by default, but you can choose not

to install support for the programming feaures you

will not use. After you select your features and com-

plete the installation, all necessary files will be in

the C:\Program Files\GPIB-488 directory.

A dialog box will prompt you to reboot the system

when you finish the installation. Click the Yes button

to reboot.

USB Devices

Follow these steps to install the hardware:

Remove the unit from its protective packaging. Save

the anti-static bubble wrap.

Before connecting the USB card to your GPIB

instruments, ensure that the instruments and PC are

at the same ground potential. Failure to do so could

damage the instruments, PC, or USB card.

Plug the USB card into an available USB port.

USB devices are plug and play. These devices con-

figure automatically. There is no need to power

cycle your PC.

Introduction and Installation Step 1. Install the Software

License Agreement

Notes

For more information on this and other Advantech

products, please visit our websites at:

http://www.advantech.com

http://www.advantech.com/eAutomation

For technical support and service:

http://www.advantech.com/support/

Part No: 2003167100

Step 2. Install the Hardware

2 Startup Manual

PCI Devices

Follow these steps to install the hardware:

Handle the board only by the edges. Static electric dis-

charge can damage the integrated circuits on the board.

Remove the interface board from its protective packag-

ing by grasping the metal rear panel. Save the anti-static

bubble package.

• Power off the computer.

• Unplug the power cord.

• Remove the computer cover.

• Install the board in any available slot.

• Use the screw to attach the rear panel bracket to the

computer case.

• Reinstall the computer cover.

• Plug in the computer and power it on.

For PCI cards in a plug-and-play operating system, the

card should configure automatically if you have

installed the software first. If you see a message about

an unrecognized board and a prompt for a disk, insert

the software CD as instructed by the operating system.

Follow these steps to test the interface:

• Go to Start>Programs>GPIB-488 and select GPIB

Diagnostic to run the hardware test program. You

can also execute the test program directly by run-

ning GPIBDiagnostic.exe in the C:\Program

Files\GPIB-488\utilities directory.

• This program tests and reports on the status of your

IEEE 488 board(s).

• Go to Start>Programs>GPIB-488 and select GPIB

Interactive Control to run the interactive pro-

gram, which allows you to communicate with the

device. You can also execute the test program

directly by running GPIBInteractiveCon-

trol.exe in the C:\Program Files\GPIB-488\util-

ities directory.

• At the prompt, type ibfind gpib0. You should see the

prompt change to gpib0.

• Type ibdev and enter the parameters based on your

device settings.

• The prompt should now have changed to User_>:.

• Type ibwrt "*idn?" and you should see a status of

0100, CMPL and a count of 5, indicating the data

was sent to the device successfully.

• Type ibrd 1000 and press <Enter>. You should see

the device identification string from the device

indicating that communication was successful.

Note 1: "*idn?" is for 488.2 devices only. For the

devices that support only 488.1, we suggest to use

"GPIBInteractiveControl.exe" to proceed with the tests.

Note 2: For more detail about using IEEE-488 com-

mands, please refer to the "GPIBProgrammingRefer-

enceManual.pdf".

Writing Custom Programs

To use your interface for custom applications, you need

to write specialized software. We have made this easy

by providing a simple set of high-level routines you can

use with all popular programming languages.

The GPIB software includes the 488.1 library, the 488.2

library, and a set of utility programs.

The 488.1 library consists of all of the functions and

subroutines that begin with the letters “ib”. The 488.1

library routines refer to devices on the GPIB bus by

their device names and handles rather than by their

GPIB addresses.

The 488.2 library consists of all the routines that do not

begin with the letters “ib”. The 488.2 library routines

refer to devices on the GPIB bus by their GPIB

addresses rather than by their names or handles.

For more information, refer to the GPIB Programming

Reference Manual, available in the root directory on

your software CD in Adobe Portable Document Format

(PDF).

Step 3. Test the Interface

GPIB-488

GPIB-488 Programming Reference Manual

Programming Reference Manual

May 2009

371930E-01

Conventions

The following conventions are used in this manual:

[ ] Square brackets indicate the key to be pressed.

»The »symbol leads you through nested menu items and dialog box options

to a final action. The sequence File»Page Setup»Options directs you to

pull down the File menu, select the Page Setup item, and select Options

from the last dialog box.

This icon denotes a note, which alerts you to important information.

This icon denotes a caution, which advises you of precautions to take to

avoid injury, data loss, or a system crash.

When symbol is marked on a product, it denotes a warning advising you to

take precautions to avoid electrical shock.

When symbol is marked on a product, it denotes a component that may be

hot. Touching this component may result in bodily injury.

bold Bold text denotes items that you must select or click in the software, such

as menu items and dialog box options. Bold text also denotes parameter

names.

italic Italic text denotes variables, emphasis, a cross reference, or an introduction

to a key concept. Italic text also denotes text that is a placeholder for a word

or value that you must supply.

monospace Text in this font denotes text or characters that you should enter from the

keyboard, sections of code, programming examples, and syntax examples.

This font is also used for the proper names of disk drives, paths, directories,

programs, subprograms, subroutines, device names, functions, operations,

variables, filenames, and extensions.

GPIB terms used within this manual are:

GPIB General Purpose Interface Bus

System controller The system controller has the unique ability to retrieve active control of the

bus or to enable devices to be remotely programmed. It takes control of the

bus by issuing an IFC (Interface Clear) message for at least 200 µsec. It also

can put devices into the remote state by asserting the REN (Remote Enable)

line.

There is always one system controller in a GPIB system. The system

controller is designated at system initialization either through the use of

hardware switches or by some type of configuration software, and is not

changed. The system controller can be the same controller as the one which

is the current active controller or an entirely different one. Note that if a

controller is both a system controller and the active controller and it passes

control to another controller, the system controller capability is not passed

along with it.

Active controller The active controller is the controller which has the ability to mediate all

communications which occur over the bus. In other words, the active

controller designates (addresses) which device is to talk and which devices

are to listen. The active controller is also capable of relinquishing its

position as active controller and designating another controller to become

the active controller.

Device A device is any IEEE-488 instrument which is not a system controller or

active controller. It can be idle or act as a talker and/or listener when

addressed or unaddressed by the active controller.

Listener A listener is any device which is able to receive data when properly

addressed. There can be up to 14 active listeners on the bus concurrently.

Some devices can also be a talker or controller; however, only one of these

functions can be performed at a time.

Talker A talker is a device which can transmit data over the bus when properly

addressed. Only one device can transmit at a time. Some devices can also

be a listener or controller; however, only one of these functions can be

performed at a time.

GPIB-488 v Programming Reference Manual

Contents

Chapter 1

GPIB Software Overview

Supported Languages.....................................................................................................1-1

GPIB Library Utility Programs......................................................................................1-2

Support for VISA Calls ...................................................................................1-2

GPIB-32.DLL Function Support.....................................................................1-2

GPIB488.DLL Function Support ....................................................................1-2

Unsupported API.............................................................................................1-3

Asynchronous API...........................................................................................1-3

GPIB32 API and GPIB488 API Differences...................................................1-3

Migrating from the GPIB32 API to the GPIB488 API ...................................1-3

Chapter 2

Programming with the GPIB Library

General Concepts...........................................................................................................2-1

Device vs. Board I/O .......................................................................................2-2

Device I/O .......................................................................................................2-2

Board l/O .........................................................................................................2-3

Device Handles................................................................................................2-3

Global Variables..............................................................................................2-3

ibsta/Ibsta()—The Status Word ........................................................2-4

iberr/Iberr()—The Error Variable .....................................................2-4

ibcnt and ibcntl/Ibcnt()—Count Variables........................................2-4

Thread Variables .............................................................................................2-4

Chapter 3

GPIB 488.1 Library Reference

IBASK ...........................................................................................................................3-3

IBCAC ...........................................................................................................................3-6

IBCLR............................................................................................................................3-7

IBCMD ..........................................................................................................................3-8

IBCMDA .......................................................................................................................3-10

IBCONFIG.....................................................................................................................3-12

IBDEV ...........................................................................................................................3-16

IBDMA ..........................................................................................................................3-18

IBEOS............................................................................................................................3-20

IBEOT............................................................................................................................3-22

IBFIND ..........................................................................................................................3-24

Contents

Programming Reference Manual vi GPIB-488

IBGTS............................................................................................................................ 3-25

IBIST ............................................................................................................................. 3-27

IBLINES........................................................................................................................ 3-28

IBLN.............................................................................................................................. 3-30

IBLOC ...........................................................................................................................3-31

IBONL...........................................................................................................................3-32

IBPAD ...........................................................................................................................3-33

IBPCT............................................................................................................................ 3-34

IBPPC............................................................................................................................ 3-35

IBRD.............................................................................................................................. 3-37

IBRDA...........................................................................................................................3-39

IBRDF ...........................................................................................................................3-40

IBRPP............................................................................................................................ 3-42

IBRSC............................................................................................................................ 3-44

IBRSP............................................................................................................................ 3-45

IBRSV ...........................................................................................................................3-46

IBSAD ...........................................................................................................................3-47

IBSIC............................................................................................................................. 3-48

IBSRE............................................................................................................................ 3-49

IBSTOP ......................................................................................................................... 3-50

IBTMO .......................................................................................................................... 3-51

IBTRG ...........................................................................................................................3-53

IBWAIT......................................................................................................................... 3-54

IBWRT .......................................................................................................................... 3-56

IBWRTA ....................................................................................................................... 3-58

IBWRTF........................................................................................................................ 3-59

Chapter 4

GPIB 488.2 Library Reference

AllSpoll.......................................................................................................................... 4-2

DevClear........................................................................................................................4-3

DevClearList.................................................................................................................. 4-4

EnableLocal................................................................................................................... 4-5

EnableRemote................................................................................................................ 4-6

FindLstn......................................................................................................................... 4-7

FindRQS........................................................................................................................ 4-9

PassControl.................................................................................................................... 4-10

PPoll .............................................................................................................................. 4-11

PPollConfig ................................................................................................................... 4-12

PPollUnconfig ............................................................................................................... 4-13

RcvRespMsg.................................................................................................................. 4-14

ReadStatusByte.............................................................................................................. 4-15

Receive .......................................................................................................................... 4-16

Contents

GPIB-488 vii Programming Reference Manual

ReceiveSetup .................................................................................................................4-17

ResetSys.........................................................................................................................4-18

Send ...............................................................................................................................4-19

SendCmds ......................................................................................................................4-20

SendDataBytes...............................................................................................................4-21

SendIFC .........................................................................................................................4-22

SendList .........................................................................................................................4-23

SendLLO........................................................................................................................4-25

SendSetup ......................................................................................................................4-26

SetRWLS .......................................................................................................................4-27

TestSRQ.........................................................................................................................4-28

TestSys...........................................................................................................................4-29

Trigger ...........................................................................................................................4-30

TriggerList .....................................................................................................................4-31

WaitSRQ........................................................................................................................4-32

Appendix A

Multiline Interface Messages

Appendix B

IBSTA

Appendix C

IBERR

Index

GPIB-488 1-1 Programming Reference Manual

GPIB Software Overview

The GPIB software includes the 488.1 library, the 488.2 library, and a set

of utility programs. The 488.1 library consists of all of the functions and

subroutines that begin with the letters “ib”. The 488.1 library routines refer

to devices on the GPIB bus by their device names and handles rather than

by their GPIB addresses.

The 488.2 library consists of all the routines that do not begin with the

letters “ib”. The 488.2 library routines refer to devices on the GPIB bus by

their GPIB addresses rather than by their names or handles.

Supported Languages

The GPIB library provides identical routines for each supported language.

Languages supported by the GPIB library at the time this manual was

published are listed below.

Table 1-1. Programming Languages

Programming Languages

Delphi

Visual Basic

Visual Basic .NET

Andere Handbücher für PCI-1671UP

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Advantech PCI-Karte Handbücher

Advantech

Advantech PCI-1220U Bedienungsanleitung

Advantech

Advantech MIO-5393 Bedienungsanleitung

Advantech

Advantech ECU-P1761 Installations- und Betriebshandbuch

Advantech

Advantech MIC-3758DIO Bedienungsanleitung

Advantech

Advantech PCI-1752USO Installations- und Betriebshandbuch

Advantech

Advantech PCI-1602UP Bedienungsanleitung

Advantech

Advantech PCIE-1803 Installations- und Betriebshandbuch

Advantech

Advantech PCIE-1805 Bedienungsanleitung

Advantech

Advantech MIC-3451 Bedienungsanleitung

Advantech

Advantech PCM-24R1TP-BE Installations- und Betriebshandbuch

Advantech

Advantech PCI-1736UP Bedienungsanleitung

Advantech

Advantech SOM-2353 Installations- und Betriebshandbuch

Advantech

Advantech PCI-1714 Bedienungsanleitung

Advantech

Advantech PCLS-848-P Bedienungsanleitung

Advantech

Advantech AIMB-228 Bedienungsanleitung

Advantech

Advantech PCI-1625U Bedienungsanleitung

Advantech

Advantech PCI-1751U Bedienungsanleitung

Advantech

Advantech PCA-6005-B Bedienungsanleitung

Advantech

Advantech PCA-5650 Installations- und Betriebshandbuch

Advantech

Advantech PCI-1758 Series Bedienungsanleitung

Advantech

Advantech PCI-1713U Bedienungsanleitung

Advantech

Advantech PCI-1711 Bedienungsanleitung

Advantech

Advantech PCM-28P1AD Installations- und Betriebshandbuch

Advantech

Advantech PCI-1752 Bedienungsanleitung

Beliebte PCI-Karte Handbücher anderer Marken

ERMA

ERMA SSI 1417 Bedienungsanleitung

SIIG

SIIG CyberSerial Dual PCI Montageanleitung

Moxa Technologies

Moxa Technologies CP-102E Bedienungsanleitung

I-Bus

I-Bus IBC2602 Bedienungsanleitung

Exsys

Exsys EX-60102 Bedienungsanleitung

Chelsio Communications

Chelsio Communications T5 Series Bedienungsanleitung

Conrad Electronic

Conrad Electronic 97 46 71 Bedienungsanleitung

Micro Innovations

Micro Innovations USB650A Bedienungsanleitung

KTI Networks

KTI Networks KF-310 Bedienungsanleitung

Asus

Asus SpaceLink WL230 Bedienungsanleitung

SIIG

SIIG SC2475 Bedienungsanleitung

TRENDnet

TRENDnet TEW-703PI Bedienungsanleitung

Belkin

Belkin F5D7000F Bedienungsanleitung

Pericom

Pericom PI7C7100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3548 Bedienungsanleitung

Digium

Digium TE200 Series Bedienungsanleitung

Allo.com

Allo.com 2nd Gen E1/T1/J1 Bedienungsanleitung

Western Digital

Western Digital FireWire PCI Adapter Bedienungsanleitung
