MIC-3758DIO

128-channel Isolated Digital I/O

CompactPCI Card

User Manual

MIC-3758DIO User Manual ii

The documentation and the software included with this product are copy-

righted 2005 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

All other product names or trademarks are properties of their respective

owners.

Part No. 2003375800 1st Edition

Printed in Taiwan June 2005

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

MIC-3758DIO User Manual iv

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring. We recommend the

use of shielded cables. This kind of cable is available from Advantech.

Please contact your local supplier for ordering information.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's

customer service center for technical support if you need addi-

tional assistance. Please have the following information ready

before you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are

included and in good condition. If any item does not accord with the

table, please contact your dealer immediately.

• 1 x MIC-3758DIO card

• 1 x Companion CD-ROM (DLL driver included)

• 1 x User Manual (this manual)

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the

products from damage.

1. To avoid electrical shock, always disconnect the power from your

PC chassis before you work on it. Don't touch any components on

the CPU card or other cards while the PC is on.

2. Disconnect power before making any configuration changes. The

sudden rush of power as you connect a jumper or install a card may

damage sensitive electronic components.

Contents

Chapter 1 General Information ....................................... 2

1.1 Introduction ....................................................................... 2

1.2 Features ............................................................................. 2

1.2.1 Wide Input/Output Range .............................................. 3

1.2.2 BoardID Switch ............................................................. 3

1.2.3 Programmable Power-Up State Function ...................... 4

1.2.4 Watchdog Timer Function ............................................. 4

1.2.5 Reset Protection ............................................................. 4

1.3 Installation Guide .............................................................. 5

Figure 1.1:Installation flow chart ................................... 5

1.4 Accessories........................................................................ 6

1.4.1 Wiring Cables ................................................................ 6

1.4.2 Wiring Terminal Boards ................................................ 6

Chapter 2 Hardware Configuration ................................ 8

2.1 Unpacking ......................................................................... 8

2.2 Hardware Installation ........................................................ 9

2.2.1 Installing a CompactPCI Card: ...................................... 9

2.2.2 Removing a CompactPCI Card .................................... 10

2.3 Board Layout................................................................... 11

Figure 2.1:MIC-3758DIO Board Layout ..................... 11

2.3.1 Connector ..................................................................... 11

Chapter 3 Pin Assignments & Jumper Settings ........... 14

3.1 Pin Assignments.............................................................. 14

Figure 3.1:Connector for MIC-3758DIO ..................... 14

Figure 3.2:I/O Connector Pin Assignments ................. 15

Table 3.1:I/O connector Signal Description ................ 16

3.2 Location of Jumper and DIP switch................................ 17

Figure 3.3:Location of Jumper and DIP Switch .......... 17

3.3 Isolated Digital Input Connections.................................. 18

3.3.1 Interrupt Function of the DI Signals ............................ 18

3.3.2 Isolated Inputs .............................................................. 18

Figure 3.4:Isolated Digital Input Connection .............. 18

3.4 Isolated Digital Output Connections............................... 19

3.4.1 Power-Up Configuration .............................................. 19

Table 3.2:JP1 Power on Config. after Hot Reset ......... 19

3.4.2 Isolated Outputs ........................................................... 19

Figure 3.5:Isolated Digital Output Connection ............ 20

3.5 Field Wiring Considerations ........................................... 20

Chapter 4 Operation ....................................................... 22

4.1 Interrupt Function............................................................ 22

4.1.1 IRQ Level .................................................................... 22

4.1.2 Interrupt Modes for Digital Input ................................ 22

MIC-3758DIO User Manual vi

Figure 4.1:Digital Input Interrupt Mode ...................... 22

4.2 Digital Filter Function..................................................... 23

Table 4.1:Pulse Widths Guaranteed ............................. 23

4.2.1 Digital Filtering Example ............................................ 24

Figure 4.2:Digital Filter Example ................................ 24

4.2.2 Digital Filter Function Control Register ...................... 24

4.3 Power-up States Function................................................ 25

4.4 Watchdog Timer Register Operation .............................. 25

4.5 BoardID Switch............................................................... 25

Table 4.2:BoardID Register of MIC-3758DIO ............ 26

Table 4.3:BoardID Setting (SW2) ............................... 26

Appendix A Specifications ................................................. 28

A.1 Specifications .................................................................. 28

A.1.1 Isolated Digital Inputs .................................................. 28

A.1.2 Isolated Digital Output ................................................. 28

A.1.3 General ......................................................................... 28

Appendix B Function Block Diagram............................... 30

B.1 MIC-3758DIO Block Diagram ....................................... 30

Appendix C Register & Structure Format....................... 32

C.1 Register Structure............................................................ 32

C.2 Digital Input Register ..................................................... 34

C.3 Digital Output Register .................................................. 35

C.4 Digital Input Rising Edge Interrupt Register ................. 36

C.5 Digital Input Falling Edge Interrupt Register ................ 37

C.6 Interrupt State Register.................................................... 38

C.7 Interrupt Of Port Identify Register .................................. 39

C.8 Digital Filter Function Control Register ........................ 40

C.9 Filter Interval Time Preset Register ................................ 41

C.10 Watchdog Counter Value Register ................................. 42

C.11 Watchdog State/Control Register ................................... 43

C.12 Watchdog Time Clear Register ...................................... 44

C.13 EEPROM Control/DO State Register ............................. 45

C.14 BoardID Register............................................................. 46

CHAPTER

General Information

This chapter gives background infor-

mation on MIC-3758DIO. It then

shows how to configure the card to

match your application and prepare it

for installation on your system..

Sections include:

• Introduction

• Features

• Installation Guide

• Accessories

MIC-3758DIO User Manual 2

Chapter 1 General Information

1.1 Introduction

Thank you for buying the Advantech MIC-3758DIO DAS card. The

Advantech MIC-3758DIO card is a powerful data acquisition (DAS) card

for the CompactPCI bus. It features a unique circuit design and complete

functions for data acquisition and control. The MIC-3758DIO card pro-

vide specific functions for different user requirements:

The following sections of this chapter will provide further information

about features of the DAS cards.

1.2 Features

The Advantech MIC-3758DIO DAS card provides users with the most

requested measurement and control functions as seen below:

Digital Output

• 64 isolated digital output channels

• High-voltage isolation on output channels (2,500 VDC )

• Wide output range (5 ~ 40 VDC )

• High-sink current for isolated output channels (90 mA max./Channel)

• Current protect for each port

• Output status read-back

• Digital output value retained after hot system reset

• Programmable Power-Up States

• Watchdog Timer

3 Chapter1

Digital Input

• 64 isolated digital input channels

• High-voltage isolation for input channels (2,500 VDC )

• Wide input range (5 ~ 25 VDC )

• High ESD protection (2,000 VDC )

• Digital Filter function

• Interrupt handling capability

• Robust Isolation

• BoardID switch

MIC-3758DIO features robust isolation protection for applications in

industrial, lab and machinery automation. MIC-3758DIO can durably

withstand a voltage up to 2,500 VDC, preventing your host system from

any incidental harms. MIC-3758DIO, if connected to an external input

source with surge-protection, can offer up to a maximum of 2,000 VDC

ESD (Electrostatic Discharge) protections for input channels.

1.2.1 Wide Input/Output Range

MIC-3758DIO has a wide range of input voltage from 5 to 25 VDC, and

it is suitable for most industrial applications with 12 VDC and 24 VDC

input voltage. MIC-3758DIO also features a wide output voltage range

from 5 to 40 VDC, suitable for most industrial applications with 12 VDC

/ 24 VDC output voltage. In the mean time, we are also ready to serve

your special needs for specific input/output voltage ranges.

1.2.2 BoardID Switch

MIC-3758DIO has a built-in DIP switch that helps define each card’s ID

when multiple cards have been installed on the same PC chassis. The

BoardID setting function is very useful when you build your system with

multiple MIC-3758DIO cards. With correct BoardID settings, you can

easily identify and access each card during hardware configuration and

software programming.

MIC-3758DIO User Manual 4

1.2.3 Programmable Power-Up State Function

User-configurable power-up states are useful for ensuring that MIC-

3758DIO powers up in a known state. Power-up states are programmed in

the EEPROM through the driver.

1.2.4 Watchdog Timer Function

The watchdog timer is a software configurable feature used to set critical

outputs to safe states in the event of a software failure. If there is loss of

communication between the application and MIC-3758DIO, if the watch-

dog timer is enabled and MIC-3758DIO does not receive a watchdog

clear software command within the interval time specified for the watch-

dog timer, the outputs go to a user-defined safe state and remain in that

state until the watchdog timer is disabled and new values are written by

the software. After the watchdog timer expires, MIC-3758DIO ignores

any writes until the watchdog timer is disabled. You can set the watchdog

timer timeout period through the WDT register to specify the amount of

time that must elapse before the watchdog timer expires. The counter on

the watchdog timer is configurable up to 232-1 x 100 ns (approximately

seven minutes) before it expires.

1.2.5 Reset Protection

If the system has undergone a hot reset (i.e. system power was not turned

off), MIC-3758DIO can either retain output values of each channel, or

return to its default configuration as power up status, depending on its on-

board jumper setting. This function protects the system from wrong oper-

ations during unexpected system resets.

Inhaltsverzeichnis

Andere Advantech PCI-Karte Handbücher

Advantech

Advantech UNO-P166 Installations- und Betriebshandbuch

Advantech

Advantech MIC-3612/3-BE Bedienungsanleitung

Advantech

Advantech PCI-1601 Bedienungsanleitung

Advantech

Advantech PCI-1718 Series Bedienungsanleitung

Advantech

Advantech DVP-7635HE Bedienungsanleitung

Advantech

Advantech SOM-2353 Installations- und Betriebshandbuch

Advantech

Advantech PCI-1752USO Installations- und Betriebshandbuch

Advantech

Advantech MOS-1110Y-0101E Bedienungsanleitung

Advantech

Advantech PCIE-1758 Series Bedienungsanleitung

Advantech

Advantech PCI-1723 Installations- und Betriebshandbuch

Advantech

Advantech PCA-6008VG Bedienungsanleitung

Advantech

Advantech PCI-1758 Series Bedienungsanleitung

Advantech

Advantech PCM-2312 Bedienungsanleitung

Advantech

Advantech PCA-5650 Installations- und Betriebshandbuch

Advantech

Advantech MIC-3756 Bedienungsanleitung

Advantech

Advantech PCA-5612 Installations- und Betriebshandbuch

Advantech

Advantech PCI-1761 Bedienungsanleitung

Advantech

Advantech PCI-1243U Bedienungsanleitung

Advantech

Advantech PCA-5630 Installations- und Betriebshandbuch

Advantech

Advantech ECU-P1706 Installations- und Betriebshandbuch

Advantech

Advantech PCI-1751 Bedienungsanleitung

Advantech

Advantech PCI-1751U Bedienungsanleitung

Advantech

Advantech PCI-1680U Bedienungsanleitung

Advantech

Advantech PCIE-1753 Bedienungsanleitung

Beliebte PCI-Karte Handbücher anderer Marken

ERMA

ERMA SSI 1417 Bedienungsanleitung

SIIG

SIIG CyberSerial Dual PCI Montageanleitung

Moxa Technologies

Moxa Technologies CP-102E Bedienungsanleitung

I-Bus

I-Bus IBC2602 Bedienungsanleitung

Exsys

Exsys EX-60102 Bedienungsanleitung

Chelsio Communications

Chelsio Communications T5 Series Bedienungsanleitung

Conrad Electronic

Conrad Electronic 97 46 71 Bedienungsanleitung

Micro Innovations

Micro Innovations USB650A Bedienungsanleitung

KTI Networks

KTI Networks KF-310 Bedienungsanleitung

Asus

Asus SpaceLink WL230 Bedienungsanleitung

SIIG

SIIG SC2475 Bedienungsanleitung

TRENDnet

TRENDnet TEW-703PI Bedienungsanleitung

Belkin

Belkin F5D7000F Bedienungsanleitung

Pericom

Pericom PI7C7100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3548 Bedienungsanleitung

Digium

Digium TE200 Series Bedienungsanleitung

Allo.com

Allo.com 2nd Gen E1/T1/J1 Bedienungsanleitung

Western Digital

Western Digital FireWire PCI Adapter Bedienungsanleitung
