VP-4x8 – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Recycling Kramer Products 2

3Overview 3

3.1 Defining the VP-4x8 4x8 VGA/UXGA Matrix Switcher 5

3.2 Using the IR Transmitter 7

4Installing in a Rack 8

5Connecting the VP-4x8 9

5.1 Connecting the VP-4x8 Rear Panel 9

5.2 Connecting the RS-232 Port to a PC or Controller 10

5.3 Connecting the RS-485 Port to a PC or Controller 11

5.4 Connecting the Ethernet Port 12

5.5 Setting the DIP-Switches 14

5.6 Cascading Machines 16

6Operating the VP-4x8 18

6.1 Displaying Unit Characteristics 18

6.2 Confirming Settings 19

6.3 Storing/Recalling Input/Output Configurations 20

6.4 Locking the Front Panel 22

7Technical Specifications 23

8Serial Communication 24

8.1 Default Communication Parameters 24

8.2 Hex Code Table 24

9Kramer Protocol 2000 25

Figures

Figure 1: UVP-4x8U4x8 VGA/UXGA Matrix Switcher Front Panel 5

Figure 2: UVP-4x8U4x8 VGA/UXGA Matrix Switcher Rear Panel 6

Figure 3: UVP-4x8UUnderside View 7

Figure 4: Connecting the UVP-4x8U4x8 VGA/UXGA Matrix Switcher 10

Figure 5: Crossed Cable RS-232 Connection 10

Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter 11

Figure 7: Local Area Connection Properties Window 13

Figure 8: Internet Protocol (TCP/IP) Properties Window 13

Figure 9: UVP-4x8UDIP-switches 14

Figure 10: Control Configuration via RS-232 and RS-485 17

Figure 11: Storing and Recalling using the Input/Output Buttons 20

VP-4x8 - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VP-4x8 4x8 VGA/UXGA Matrix

Switcher, which is ideal for the following typical applications:

•Any professional display system requiring a true 4x8 computer graphics

matrix operation

•Multimedia and presentation source, and acceptor selection

2 VP-4x8 - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance, high-resolution cables

•Use only the power cord that is supplied with this machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer VP-4x8 away from moisture, excessive sunlight and

dust

2.2 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VP-4x8 - Overview 3

3 Overview

The VP-4x8 is a high-performance, high-resolution computer graphics video

switcher. The VP-4x8 lets you simultaneously route any or all of the four inputs to

any or all of the eight outputs and to loop each input to an additional output.

The VP-4x8 4x8 VGA/UXGA Matrix Switcher features:

•Video bandwidth of 400MHz that ensures transparent performance even in

the most critical applications

•HDTV compatibility

•Looping inputs

•12 preset memory locations for quick access to common configurations

•Delayed switching mode (ranging from 0 to 3.5 sec, in increments of 0.5sec)

for clean transitions (seamless switching) when switching between

non-genlocked sources

•DC coupled inputs and outputs

•Kr-isp™ advanced sync processing technology, which provides a sharp,

stable image when the sync level is too low, by restoring the sync signal

waveform

•A TAKE button that allows you to place multiple switches in a queue and

then activate them simultaneously with one touch of this button

•A LOCK button to prevent tampering with the front panel

•Automatic detection of connected input signals (respective button

illuminates)

Control the VP-4x8 using the front panel buttons, or remotely via:

•RS-485 or RS-232 serial commands transmitted by a PC, touch screen

system, or other serial controller

•The Kramer infrared remote control transmitter

•Ethernet

•An external remote IR receiver (optional)

4 VP-4x8 - Overview

The VP-4x8 is a dependable and rugged unit that fits into one vertical space (1U)

of a standard 19-inch professional rack.

The RGBHV signals are connected on 15-pin HD pin connectors to reduce enclosure size.

VP-4x8 - Overview 5

VP-4x8 – Overview 5

3.1 Defining the VP-4x8 4x8 VGA/UXGA Matrix Switcher

This section defines the VP-4x8.

Figure 1: VP-4x8 4x8 VGA/UXGA Matrix Switcher Front Panel

# Feature Function

1 IR Receiver The red LED is illuminated when receiving signals from the infrared remote control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 IN SELECTOR Buttons Select the input to switch to the output.

When a signal is detected, the input button illuminates in green

4 OUT SELECTOR Buttons Select the output to which the input is switched

5 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs

6 OFF Button Press an OUT SELECTOR button and then an OFF button to disconnect that output from the inputs

Press the ALL button and then the OFF button to disconnect all the outputs

7 TAKE Button Pressing TAKE toggles the mode between the Confirm mode (in the Confirm mode, the TAKE button

illuminates) and the At Once mode (user confirmation per action is unnecessary)

8 STO (Store) Button Pressing STO followed by an input/output button stores the current setting

9 RCL (Recall) Button Pressing the RCL button and the corresponding IN/OUT button recalls a setup from the non-volatile

memory. The stored status flashes. Pressing a different IN/OUT button lets you view another setup.

After making your choice, pressing the RCL button again implements the new status

10 LOCK Button Disengages the front panel switches

11 STATUS 7-segment Display Displays the selected input switched to the output (marked above each input)

Also displays the number of IN and OUT ports, the firmware version number, and the MACHINE #. See

Section 6.1

6 VP-4x8 - Overview

Figure 2: VP-4x8 4x8 VGA/UXGA Matrix Switcher Rear Panel

Feature

Function

12 LOOP 15-pin HD (F) Connectors Connect looped input to output acceptor (1 to 4)

13 INPUT 15-pin HD (F) Connectors Connect to the video sources (from 1 to 4)

14 OUTPUT 15-pin HD (F) Connectors Connect to the output acceptor (from 1 to 8)

15 FLASH PROG Button Push in for “Program” to upgrade to the latest Kramer firmware (see separate firmware upgrade

guide), or release for Normal (the factory default). The FLASH PROG “Reset” button is located

on the underside of the unit

16 DELAY,MACH# and RS-485 TERM

DIP-switches DIP-switches to set delay (DIPs 1-3), set the machine # (DIPs 4-7) and terminate the RS-485

connection (DIP 8) (see Section 5.5)

17 RS-232 9-pin D-sub (F) Port Connects to the PC or remote controller

18 ETH PROG Button Push in to upgrade ETH firmware, release for normal operation

19 ETHERNET RJ-45 Connector Connects to the PC or other serial controller through computer networking

20 ETH Factory Reset Button Press to reset to factory default definitions:

IP number −192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

First disconnect the power cord and then

connect it again while pressing the ETH Factory

Reset button. The unit will power up and load its

memory with the factory default definitions

21 RS-485 Terminal Block Port Pin G is for ground connection; pins B (-) and A (+) are for RS-485

22 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the machine via an IR remote controller

(instead of using the front panel IR receiver)

23 Power Connector with Fuse AC connector enabling power supply to the unit

6VP-4x8 – Overview

VP-4x8 - Overview 7

Figure 3 illustrates the underside of the VP-4x8 unit.

Figure 3: VP-4x8 Underside View

Feature

Function

RESET FOR PROGRAM Button Press to reset unit prior to firmware upgrade (see

separate firmware upgrade guide)

3.2 Using the IR Transmitter

You can use the RC-IR3 IR transmitter to control the machine via the built-in IR

receiver on the front panel or, instead, via an optional external IR receiver (Model:

C-A35M/IRR-50). The external IR receiver can be located up to 15 meters away

from the machine. This distance can be extended to up to 60 meters when used

with three extension cables (Model: C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm

connector that fits into the REMOTE IR opening on the rear panel. Connect the

external IR receiver to the REMOTE IR 3.5mm connector.
