Leica DM750 M Bedienungsanleitung
Leica DM750
User Manual
Leica DM750 User Manual 2
Published in January 2015 by:
Leica Microsystems (Schweiz) AG
Max Schmidheiny Strasse 201
CH-9435 Heerbrugg (Switzerland)
In case of questions, please contact the hotline:
Manufacturer Information
Leica DM750 User Manual 3
Chapter Overview
Safety Regulations 5
The Leica DM750 16
Ready! 19
Set! 29
Go! 42
Care of the Microscope 44
Troubleshooting 47
Dimensions 50
Leica DM750 User Manual 4
Contents
Safety Regulations
Safety Concept 6
Symbols Used in This Instruction Manual 7
Important Notes 8
Instructions on Use 9
Health Risks and Dangers of Use 11
Information for the Person Responsible for the Instrument 12
Care Instructions 13
Accessories, Maintenance and Repair 14
Electrical Data and Ambient Conditions 15
The Leica DM750
Introduction 17
Unpacking 18
Ready!
Substage Illumination 20
Attaching the Viewing Tubes 21
Leica EZ Viewing Tube – Integrated Eyepieces 22
Leica Standard Viewing Tube – Separated Eyepieces 24
Eyecups 25
Installing Objectives 26
Installing the Substage Condenser 27
Set!
Turning on the Microscope 30
Complete Condenser Centering 31
Using the Condenser 32
Prepare to View a Specimen Slide 33
Focusing 34
Viewing Tube Adjustment 35
Koehler Configuration 37
Oil Immersion Technique 39
Time Delay Shutoff 41
Go!
Ready! Set! Go! 43
Care of the Microscope
General Maintenance 45
Troubleshooting
Troubleshooting 48
Dimensions
Dimensions 51
Leica DM750 User Manual Safety Regulations 5
Safety Regulations
Leica DM750 User Manual Safety Regulations 6
Safety Concept
The individual modules of the Leica DM micros-
copy series include an interactive CD-ROM with
all relevant user manuals in several languages.
Keep it in a safe place, and readily accessible
to the user. User manuals and updates are also
available for you to download and print from
our website at www.leica-microsystems.com.
This user manual describes the special func-
tions of the individual modules of the Leica
DM microscopy series and contains important
instructions for their operational safety, main-
tenance, and accessories.
The "Safety concept" booklet contains addi-
tional safety information regarding the service
work, requirements and the handling of micro-
scope, accessories and electrical accessories
as well as general safety instructions. You can
combine individual system articles with articles
from external suppliers. Please read the user
manual and the safety requirements of the
supplier.
Before installing, operating or using the instru-
ments, read the user manuals listed above. In
particular, please observe all safety instructions.
To maintain the unit in its original condition
and to ensure safe operation, the user must
follow the instructions and warnings contained
in these user manuals.
Leica DM750 User Manual Safety Regulations 7
Symbols Used in This Instruction Manual
Warning of a danger
This symbol indicates especially impor-
tant information that is mandatory to
read and observe.
Failure to comply can cause the following:
OHazards to personnel
OFunctional disturbances or damaged
instruments
Warning of hazardous electrical voltage
This symbol indicates especially impor-
tant information that is mandatory to
read and observe.
Failure to comply can cause the following:
OHazards to personnel
OFunctional disturbances or damaged
instruments
Danger due to hot surface
This symbol warns against touching
accessible hot surfaces, e.g. those of
light bulbs.
Important information
This symbol indicates additional infor-
mation or explanations that intend to
provide clarity.
Explanatory notes
fThis symbol within the text points to addi-
tional information and explanations.
Instructions for disposing of the
instrument, accessory components,
and consumables.
Leica DM750 User Manual Safety Regulations 8
Important Notes
Description
The Leica DM750 microscope meets today's
state of the art of technology. Nevertheless,
hazards may still arise during operation. The
potential risks are described below.
Before installing, operating or using the
instrument, it is mandatory to read this
user manual. In particular, please observe all
safety instructions.
User manual
This user manual includes important instruc-
tions related to operating safety, maintenance
and accessories.
Your Leica DM750 microscope comes
with an interactive CD-ROM with all
relevant user manuals. Keep it in a safe place,
and readily accessible to the user. User manu-
als and updates are also available for you
to download and print from our website at
www.leica-microsystems.com.
Accessories from third-party suppliers
You can combine individual system articles with
articles from external suppliers. Please read the
user manual and the safety requirements of the
supplier.
Original condition
To maintain the unit in its original condition
and to ensure safe operation, the user must
follow the instructions and warnings contained
in these user manuals.
Legal requirements
Adhere to general and local regulations relat-
ing to accident prevention and environmental
protection.
EC Declaration of Conformity
Electrically operated accessories are
constructed based on the state of the art of
technology and are provided with an EC Decla-
ration of Conformity.
Leica DM750 User Manual Safety Regulations 9
Instructions on Use
The Leica DM750 microscope may be
used only in closed rooms and must be
placed on a solid substrate.
The Leica DM750 microscope can be used in
clean rooms without any problems.
Always position the Leica DM750 micro-
scope so that you can disconnect it from
the power supply at any time. The power cable
must remain accessible at all times, because it is
intended as a power disconnect device.
Place of use
Only use the instruments in closed, dust free
rooms and between +10°C and +40°C. Protect
the devices from oil, chemicals and extreme
humidity. If using the devices outdoors, protect
them from dust and moisture. Never use electri-
cal devices outdoors. Install electrical devices at
least 10 cm from the wall and away from flam-
mable substances.
Avoid large temperature fluctuations, direct
sunlight and vibrations. These conditions
can distort measurements and micrographic
images.
In warm and warm-damp climatic zones,
the individual components require
special care in order to prevent the build-up of
fungus.
Non-intended use
Never install any other plug or unscrew
any mechanical components unless
expressly instructed to do so in the instructions.
The devices and accessories described in
this instruction manual have been tested
for safety and potential hazards.
The responsible Leica affiliate must be
consulted whenever the instrument is
altered, modified or used in conjunction with
non-Leica components that are outside of the
scope of this manual!
Unauthorized alterations to the instru-
ment or noncompliant use shall void all
rights to any warranty claims.
Leica DM750 User Manual Safety Regulations 10
Instructions on Use (Continued)
Transport
If at all possible, use the original packaging for
shipping or transporting individual modules.
In order to prevent damage from vibrations,
disassemble all moving parts that (according to
the user manual) can be assembled and disas-
sembled by the customer and pack them sepa-
rately.
Disposal
Once the product has reached the end of its
service life, please contact Leica Service or Sales
about disposal.
Please observe and ensure compliance with the
national laws and regulations that implement,
for example, the EC Directive WEEE.
Like all electronic devices, this instru-
ment, its accessory components
and consumables must never be disposed of
with general household waste. Disposal must
comply with locally applicable laws and regula-
tions.
Integration in third-party products
When installing Leica products into third-party
products, the manufacturer of the complete
system or its dealer is responsible for follow-
ing all applicable safety instructions, laws and
guidelines.
