Metra Electronics 99-7365B Bedienungsanleitung

REV. 3/4/2015 INST99-7365B

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

Installation instructions for part 99-7365B

• ISODINradioprovisionwithpocket

• Painted matte black

•A)Radiotrimpanel•B)Brackets•C)Pocket•D)(4)#8x3/8”Phillipsscrews

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS(soldseparately)

WiringHarness:•70-7304

AntennaAdapter:•Notrequired

•Phillipsscrewdriver•Panelremovaltool

TOOLS REQUIRED

Kia Sedona 2015-up

99-7365B

A CB D

Dash Disassembly

–KiaSedona2015-up............................................ 2

Kit Assembly

–ISO DINradioprovisionwithpocket...................... 3

Table of Contents

99-7365B

Dash Disassembly

1. Unclipthetrimflaponthetopof

thesteeringcolumn.(FigureA)

2. Unclipandremovethebezel

surroundingtheradioand

instrumentcluster.(FigureB)

3. Removefourscrewssecuring

theradio,unplugtheradiofrom

thefactoryradioandantenna

connectors.(FigureC)

Continue to kit assembly

(Figure A) (Figure B) (Figure C)

99-7365B

Kit Assembly

ISO DIN radio provision with pocket

1. Mountthepockettotheradio

bracketswiththefourofthe

#8x3/8”Phillipsscrewssupplied.

(FigureA)

2. Removethemetal“DIN”sleeve

andtrimringfromthe

aftermarketradio.

3. Mountthebracket/pocket

assemblytotheradiowiththe

screwssuppliedwiththeradio.

(FigureB)

4. Snaptheradiohousingtrimpanel

intothefactorytrimbezelfromthe

backsideofthebezel.(FigureC)

5. Locatethefactorywiringharness

andantennapluginthedashand

makeallnecessaryconnectionsto

thenewradio.Metrarecommends

usingthepropermatingadapters

fromMetraand/orAXXESS.

6. Afterconnectingallwiring,mount

thenewradioassemblyintothe

dashwiththefactoryscrewsand

reassemblethedashinreverse

orderofdisassembly.

(Figure A)

(Figure B)

(Figure C)

REV. 3/4/2015 INST99-7365B

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

Installation instructions for part 99-7365B
