Vacmaster VSH01 Bedienungsanleitung

www.vacmaster.com

Cleva North America, Inc.

Greenville, SC 29607

Made in China

Use & Care Guide

MODEL NO. VSH01

2-in-1 Corded Stick Vacuum

(866) 384-8432

-2-

SECTION

Important Safety Instructions...................................................................................................................3

Warranty…………....................................................................................................................................4

Technical Data

........................................................................................................................................4

Getting To Know Your Vacuum................................................................................................................5

General Assembly Instructions.............................................................................................................6-8

Operating Instructions........................................................................................................................9-13

Maintaining Your Vacuum................................................................................................................ 14-17

Troubleshooting................................................................................................................................18-19

TABLE OF CONTENTS

PAGE

Thank you for purchasing this Vacmaster® vacuum cleaner. With it you are

obtaining a high quality product that is engineered for optimal performance.

FOR YOUR SAFETY

Read and understand this manual before use.

Keep this manual and your sales check (receipt) in a safe place for future

reference.

-3-

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER

Failure to follow the warnings and instructions may result in electric shock, re

and/or serious injury.

WARNING - To reduce the risk of re, electric shock, or injury:

• Do not leave appliance when plugged in. Unplug from outlet when not in use

and before servicing.

• Do not use outdoors or on wet surfaces.

• Do not allow to be used as a toy. Close attention is necessary when used by or

near children.

• Use only as described in this manual. Use only manufacturer’s recommended

attachments.

• Do not use with damaged cord or plug. If appliance is not working as it should,

has been dropped, damaged, left outdoors, or dropped into water, return it to a

service center.

• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull

cord around sharp edges or corners. Do not run appliance over cord. Keep cord

away from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any object into openings. Do not use with any opening blocked; keep

free of dust, lint, hair, and anything that may reduce air ow.

• Keep hair, loose clothing, ngers, and all parts of body away from openings and

moving parts.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or combustible liquids, such as gasoline, or

use in areas where they may be present.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches,

or hot ashes.

• Do not use without the lter in place.

SAVE THESE INSTRUCTIONS

Household use only

-4-

FOR ONE YEAR from the date of sale, this product is warranted against defects

in material or workmanship when it is assembled, operated and maintained

according to all supplied instructions.

WITH PROOF OF SALE, a defective appliance will be replaced free of charge.

For warranty coverage details to obtain free replacement, visit the web page:

www.vacmaster.com or call (866) 384-8432.

• This warranty does not cover lters, which are expendable parts that

can wear out from normal use within the warranty period.

• This warranty is void if this product is ever used for other than private household

purposes.

• This warranty gives you specic legal rights, and you may also have other

rights which vary from state to state.

TECHNICAL DATA

2-in-1 Corded Stick Vacuum

Model: VSH01

Rated Voltage: 120V AC

Rated Frequency: 60Hz

Nominal Current: 3.3A

WARRANTY

-5-

GETTING TO KNOW YOUR VACUUM

REPLACEMENT PARTS

Available online at www.vacmaster.com or call (866) 384-8432.

Item Part No.

Filter 571001109

Crevice Tool 571001135

Handle

Upper Cord Hook

Wand

Wand Latch

Lower Cord Hook

Power Cord

Floor Nozzle

Dust Release Button

Dust Cup

Hand Vacuum

Dust Cup Release Button

On/Off Switch

HEPA Filter

Crevice Tool

-6-

1. Align and insert the oor nozzle into the suction port of the hand vacuum.

2. Open the wand latch located on the top of the hand vacuum.

GENERAL ASSEMBLY INSTRUCTIONS

Wand Latch

-7-

3. Insert the end of the wand into the hole with the front of the wand aligning with

indent of the hand vacuum. Secure the wand by closing the latch until you

hear a click.

4. Make sure the upper cord hook is in upright position as shown. Wrap the

power cord loosely around the upper and lower cord hooks.

Upper Cord Hook

Lower Cord Hook

Wand Latch

-8-

5. Lock power cord plug onto the power cord.

WARNING

Wrapping the cord too tightly with excessive stress on the cord can cause

cord damage. A damaged cord is an electrical shock hazard and could cause

personal injury or damage.

Power Cord Plug

Power Cord

-9-

OPERATING INSTRUCTIONS

Before using, choose the stick or hand vacuum mode for cleaning.

Using Your Stick Vacuum

Note: Make sure the vacuum cleaner is completely assembled and the dust cup is

empty before using.

1. Turn the upper cord hook to either side to release the power cord.

2. Plug the power cord plug into an outlet located near the oor.

Upper Cord Hook

-10-

WARNING

To reduce the risk of electric shock, this appliance has a polarized plug (one

blade is wider than the other). This plug will t in a polarized outlet only one

way. If the plug does not t fully in the outlet, reverse the plug. If it still does not

t, contact a qualied electrician to install the proper outlet. Do not change the

plug in any way.

WARNING

• When any abnormality/failure occurs, stop using the product immediately and

disconnect the power plug.

• DO NOT use outlets above counters.

• Damage of the cord resulting from the surrounding objects could occur.

3. Press the on/off switch to the ‘I’ position to start the vacuum.

4. Once you have completed vacuuming, press the on/off switch to the ‘O’

position and unplug the power cord from the outlet.

On/Off Switch I = ON

O = OFF
