Wasp WWR2900 Betriebsanleitung

Wasp Barcode Technologies

1400 10th Street

Plano, TX 75074

www.waspbarcode.com 0308 US

Programming Guide

Barcode Scanning Made Easy

No part of this publication may be reproduced or transmitted in any form or by any

means without the written permission of Wasp Barcode Technologies. The information

contained in this document is subject to change without notice.

Wasp and the Wasp logo are registered trademarks of Wasp Barcode Technologies. All other

trademarks or registered trademarks are the property of their respective owners.

PenScannerProgrammingGuide

Please Read

Note:

The Wasp®WWR2900 Series Scanners

are ready to scan the most popular barcodes out of the box.

This manual should only be used to make changes in the

configuration of the scanner for specific applications. These

scanners do not require software or drivers to operate. The

scanner enters data as keyboard data. Please review this manual

before scanning any of the programming barcodes in this manual.

Tech Tip

If you are unsure of the scanner configuration or have scanned

the incorrect codes, please scan the default barcode on page 7.

This will reset the scanner to its factory settings.

Check Version

Wasp Barcode Technologies

Productivity Solutions for Small Business that

Increases Productivity & Profitability

• Barcode, data colection solutions

• Small business focus

• Profitable growth since 1986

• Over 200,000 customers

• Business unit of Datalogic SPA

Wasp®Barcode Technologies

1400 10th Street

Plano, TX 75074

Phone: 214-547-4100 • Fax: 214-547-4101

www.waspbarcode.com

Table of Contents

Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 2. Barcode Symbologies. . . . . . . . . . . . . . . . . . . . 2

Chapter 3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 4. Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 5.

Setup & Configuration

. . . . . . . . . . . . . . . . . . 5-28

1. Factory Default & Keyboard Connection . . . 6

2. Beep and Delay . . . . . . . . . . . . . . . . . . . . 7-8

3. Upper/Lower Case. . . . . . . . . . . . . . . . . . . . 9

4. Keyboard Language. . . . . . . . . . . . . . . . . . 10

5. Preamble/Postamble Configuration. . . . . . 11

6. Terminator/Code ID . . . . . . . . . . . . . . . . . . 12

Enable/Disable Barcode Symbologies

. . . . . 13-14

8. Barcode Symbology Settings . . . . . . . . 15-27

Code 39. . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Interleaved 2 of 5 and Code 93 . . . . . . . . . 16

Code 128 and UCC/EAN 128 . . . . . . . . . . . 17

MSI/Plessey . . . . . . . . . . . . . . . . . . . . . . . 18

Codabar. . . . . . . . . . . . . . . . . . . . . . . . . . . 19

UPC-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

UPC-A Supplemental. . . . . . . . . . . . . . . . . 21

UPC-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

UPC-E Supplemental . . . . . . . . . . . . . . . . . 23

EAN-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

EAN-8 Supplemental . . . . . . . . . . . . . . . . . 25

EAN-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

EAN-13 Supplemental . . . . . . . . . . . . . . . . 27

Appendix A Barcode Test Symbols . . . . . . . . . . . . . . . 28-30

Appendix B ASCII Table . . . . . . . . . . . . . . . . . . . . . . . . 31-34

Appendix C Codes for PC . . . . . . . . . . . . . . . . . . . . . . . . . 35

Appendix D Technical Specifications . . . . . . . . . . . . . . . . . 36

Product Support. . . . . . . . . . . . . . . . . . . . . . . 37

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Frequently Asked Questions. . . . . . . . . . . . . . 38

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 1

Chapter 1

Introduction

Barcoding is the most common Automated Data Collection (ADC)

technology providing timely, error-free information that can be used to

increase productivity, accuracy, and efficiency in the workplace. Virtually

every type of industry is using barcodes to replace keyboard data entry.

Studies have shown that a proficient data entry operator will make one

error for every 300 characters that are manually entered. The error rate

using barcodes is almost negligible and can be error-free using barcode

symbologies with the check digit enabled.

A wand is a pen-style scanner requiring physical contact with a barcode

when scanning. The wand is simple to use but does require the user to

maintain a tilt angle above the label surface. This controls the reflectance

of the light that is absorbed. A constant or continuous scanning motion

across the barcode must be maintained to regulate the sample rate. The

speed in which the user moves across the barcode is also important. If the

continuous scanning motion is too slow or too fast, the decoder may not

be able to detect the signal sent to it by the wand.

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 2

Chapter 2

Barcodes are symbols consisting of a series of bars and spaces which can

be applied to packages, cartons, bottles, and other commercial products.

The bars and spaces in each symbol are grouped in such a way to

represent a specific ASCII character or function. The interpretation of

these groups is based on a particular set of rules called symbologies.

Various symbologies have been developed for particular applications.

Some examples are shipping and receiving, manufacturing, retail,

healthcare, transportation, document processing and tracking, and

libraries.

The resolution of a barcode is dependent on the narrowest element of a

barcode (X dimension), and can vary from high density (nominally less

than 0.009 in./0.23 mm), medium density (between 0.009 in./0.23 mm and

0.020 in./0.50 mm), and low density (greater than 0.020 in./0.50 mm).

Medium and low densities are the most common since these are the

easiest to read (scan) with nearly all scanning devices. Wasp WWR2900 /

2905 Scanners can read barcodes with X-dimensions as low as 5 mils

(0.005 in/0.13mm).

Wasp WWR2900 / 2905 Scanners can read the most popular barcode

symbologies including Code 39, Code 93, Code 128, Interleaved 2 of 5,

UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, Codabar, and MSI/Plessey.

Please see test chart on pages 29-31.

Barcode Symbologies

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 3

Chapter 3

Installation

1. Turn off your computer.

2. Unplug your PC keyboard cable and plug the male end (Din 6) of the

Wasp WWR2900 Scanner directly into your PC keyboard port.

Plug your keyboard cable into the other end (female Din 6) of the the

Wasp WWR2900 Scanner.

3. Turn your computer on.

1. Plug the USB of the Wasp WWR2905 Scanner directly into your PC’s

USB port.

WWR2905 USB Scanner

WWR2900 PS2 Pen Scanner

Scanning Aperture

Din-6M

Din-6F

USB Port

Scanning Aperture

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 4

Chapter 4

Your Wasp WWR2900 / 2905 Scanners are ready for use. The default

settings of the Wasp WWR2900 / 2905 Scanners have been pre-

programmed for the most common barcode configurations. Use the

“WWR2900 / 2905 Scanners Setup & Configuration” sections only to

customize the Wasp WWR2900 / 2905 Scanners settings. Please review

the “Enable Barcode Symbologies” configuration beginning on page 14 to

see the list of barcode symbologies which are enabled by default.

Tip:

•Use the pre-printed “Barcode Test Symbols” in Appendix A on pages

29-31 as a test chart to practice scanning.

Quick Start

USB Connection

PS2 Connection

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 5

Chapter 5

In order to configure Wasp WWR2900 / 2905 Scanners, you must

familiarize yourself with the setup procedures on the following pages. The

default settings of the scanners are identified on each page and clearly

marked using an asterisk (*). The default settings have been

preprogrammed for the most common barcode configurations. Use the

setup & configuration barcodes only to customize the Wasp WWR2900 /

2905 Scanners settings. If you need to configure the Scanner, the default

settings will be overwritten. All the programmed settings are stored

permanently in non-volatile memory; therefore, your configuration will be

maintained even if the keyboard power to Wasp WWR2900 / 2905

Scanners are removed by turning off your PC.

In order to configure Wasp WWR2900 Series Scanners,

two basic steps need to be followed:

(1) Locate the group that contains the options to be changed.

(2) Scan the barcode representing the option to be changed.

The scanner will sound two beeps.

To change Minimum/Maximum Length:

(1) Scan the Minimum or Maximum Length barcode.

(2) Scan a 2 digit value from the ASCII table on pages 32-35

(3) Scan the Minimum or Maximum Length barcode again.

Setup & Configuration

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 6

Chapter 5

FACTORY DEFAULT & KEYBOARD CONNECTION

Use the Factory Default barcode to reset the scanner to the Default

settings. Scan this barcode to reset the scanner if you are unsure of how

your Wasp WWR2900 / 2905 Scanners are configured:

PC (USB or PS/2) * Notebook

The Keyboard Connection is used to program the Wasp WWR2900 / 2905

Scanners for the type of computer you are connecting to.

*Default

Keyboard Connection

Factory Default

F a c t o ry Default

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 7

Chapter 5

BEEP AND DELAY

The ‘Beep and Delay’ configuration supports the general control options

for the Wasp WWR2900 / 2905 Scanners. These options include the

volume, intercharacter delay, and interblock delay.

Interblock delay is the minimum time interval between two adjacent scans.

If the processing speed of your host device is slower than your scanning

speed, a longer interblock delay may ensure the data integrity.

Intercharacter delay is the time period that the scanner will wait before

transmitting the next character. If data sent by the scanner has incorrect or

missing characters, a longer intercharacter delay may solve the problem.

The intercharacter delay should be changed only if the transfer rate cannot

be maintained between the Wasp WWR2900 / 2905 Scanners and the

keyboard buffer of the computer.

Note: The default for the intercharacter delay is set to ‘140us’ and is the

most common configuration; however, your PC may be different. When

you scan a barcode, if some stray or scrambled characters appear,

increase the intercharacter delay to slow down the transfer rate.

Beep Off

Beep Medium *

Beep High to Low

Beep Hi

Beep Low to High

Beep Low

Beep Settings

*Default

WWR2900_2905Manual0308_sm.A0 6/25/08 4:43 PM Page 8

Inhaltsverzeichnis

Andere Wasp Barcode-Lesegerät Handbücher

Wasp

Wasp WWS800 Bedienungsanleitung

Wasp

Wasp WLP 4170 Betriebsanleitung

Wasp

Wasp Wasp WDI7500 Installations- und Betriebshandbuch

Wasp

Wasp WWS550i Installationsanleitung

Wasp

Wasp WPL205 Bedienungsanleitung

Wasp

Wasp WWS750 Bedienungsanleitung

Wasp

Wasp WLS9600 Bedienungsanleitung

Wasp

Wasp WDI4500 Bedienungsanleitung

Wasp

Wasp WWS110i Bedienungsanleitung

Wasp

Wasp WPL308 Bedienungsanleitung

Wasp

Wasp WWS110i Bedienungsanleitung

Wasp

Wasp WWS800 Bedienungsanleitung

Wasp

Wasp WLS8600 Bedienungsanleitung

Wasp

Wasp N1181 Betriebsanleitung

Wasp

Wasp WLR8950 Bedienungsanleitung

Wasp

Wasp WWS800 Bedienungsanleitung

Wasp

Wasp WWS550i Bedienungsanleitung

Wasp

Wasp WDI4500 Bedienungsanleitung

Wasp

Wasp WPL608 Bedienungsanleitung

Wasp

Wasp WRS100SBR Bedienungsanleitung

Wasp

Wasp WPL610 Bedienungsanleitung

Wasp

Wasp WDI4700 Bedienungsanleitung

Wasp

Wasp WDI4600 Bedienungsanleitung

Wasp

Wasp WLR8900 Betriebsanleitung

Beliebte Barcode-Lesegerät Handbücher anderer Marken

POSMicro

POSMicro Datalogic PowerScan D7100 Bedienungsanleitung

Marson

Marson MT780 Kurzanleitung zur Einrichtung

NCR

NCR RealPOS Bedienungsanleitung

Motorola

Motorola SE3300 Kurzanleitung zur Einrichtung

Element

Element P130BT Bedienungsanleitung

Motorola

Motorola Symbol LS3008 Installations- und Betriebshandbuch

Meec tools

Meec tools OBD-II / VAG Bedienungsanleitung

SICK

SICK CLP 100 Bedienungsanleitung

Royal Tag SA

Royal Tag SA I-Read Bedienungsanleitung

Welch Allyn

Welch Allyn IMAGETEAM 3800 Bedienungsanleitung

Meteor

Meteor 8310 Bedienungsanleitung

Denso

Denso BHT-500B Bedienungsanleitung

Datalogic

Datalogic Heron HD3130 Bedienungsanleitung

Motorola

Motorola MP6000 Montageanleitung

Newland

Newland NLS-HR15-BT Bedienungsanleitung

ARTDEV

ARTDEV AS-1310 Bedienungsanleitung

Aopos

Aopos AS290 Bedienungsanleitung

ENS

ENS 367-5455 Bedienungsanleitung
