Eneo DTR-2009/250CD Bedienungsanleitung

Operating Instructions

Digital Video Recorder

Models: DTR-2009/250CD, DTR-2016/250CD,

DTR-2009/500CD, DTR-2016/500CD,

DTR-2009/750CD DTR-2016/750CD

DTR-20XX

Safety instructions

EMC class

This digital video recorder (DVR) is a class A device in accordance with EN 55022.

This device may cause interference to other equipment in domestic use. In such cases the persons opera-

ting the DVR are required to provide appropriate countermeasures, for which they themselves bear the cost.

►

Importance of these Operating Instructions

Please read the safety instructions and the other information contained in the Operating Instructions before

connecting up and operating the DVR.

The Operating Instructions should be kept in a safe place for later reference.

►

Ambient conditions

The DVR should be protected against excessive heat, dust, moisture and vibration.

The DVR may only be operated at temperatures between +5°C and +40°C, and up to a maximum air

humidity of 90%.

The DVR may only be operated indoors, and must be protected against ingress of water and moisture.

►

Care of the DVR

Never switch on the DVR when moisture has penetrated it. In such cases, have the DVR checked by a

qualied service engineer.

Do not place any heavy objects on the DVR.

Never cover over the DVR‘s vents.

Never insert metal objects or any other items into the vents. This may permanently damage the DVR.

The housing may only be opened by authorised persons. Repairs may only be carried out by qualied

service personnel.

The DVR must be disconnected from the power supply before its housing is opened.

►

Getting started with the DVR

When laying the connecting cables, make sure no weight is placed on them, that they are not kinked or

damaged, and that no moisture can penetrate them..

►

Cleaning

The housing of the DVR may only be cleaned with a moisture (not wet) cloth.

Use only a mild detergent. Do not use solvent-containing detergents or petrol. This could permanently

damage the surface nish.

►

Spare parts

Use only original spare parts from Videor Technical GmbH..►

DTR-20XX

Table of contents

Overview 7

Package contents 7

Basis functions 7

Features 7

Requirements for operation 7

Control options 7

Connections on the rear 8

Front panel controls 9

Key to controls 10

Function buttons 10

PTZ camera functions 10

Playback functions 10

Remote control functions 11

Playback functions 11

Menu overview 12

Accessing the menus 14

Accessing the Display menu 14

Accessing the PTZ menu 14

Accessing the Setup menu 15

Accessing the Search menu 15

Getting started 16

Checklist for DVR operation 16

Connecting the remote control and DVR 16

Switching on the DVR 17

Switching off the DVR 17

Administration 18

Saving your system setup 18

Loading your system setup 18

Deleting recordings 18

Downloading software updates 19

Hiding from specic users 19

Restoring factory defaults 19

Determining the memory requirement of a recording 20

Searching for recordings 21

Using calendar search 22

Using event log search 23

Using text-in search 24

Using motion search 25

Copying recordings 26

6DTR-20XX

Table of contents

Menu descriptions – Setup menu 27

System – Information 28

System – Date/Time 29

System – Storage 30

System – User 32

System – Shutdown 33

System – Log out user1... 33

Network – Network 33

Network – Notication 36

Devices – Camera 37

Devices – Audio 38

Devices – Alarm-Out 39

Devices – Display 40

Devices – Remote Control 41

Record – Record 42

Record – Schedule 43

Record – Pre-Event 44

Record – Archive 45

Event – Alarm-In 46

Event – Motion Detection 48

Event – Video Loss 50

Event – Text-In 52

Event – System Event 54

Event – Event Status 56

Specications DTR-2009 57

Specications DTR-2016 59

Accessories 61

Supported PTZ cameras 62

Index 63

Notes on disposal 66

DTR-20XX

Overview

Package contents

Digital video recorder (DVR)

Mains power cord

Operating instructions

RAS (Remote Administration System) software on CD

Operating instructions for RAS software on paper and CD

Mounting kit for rack installation

Screws for attaching SCSI Connector

Mounting screws and guide for installation of hard disk drives

Infrared remote control

Basis functions

Recording of video images from multiple cameras

Event-triggered start of recording

Video playback

Search for specic video sequences

Features

MPEG-4 compression / duplex mode

9 or 16 loop-through inputs / VGA, S-VHS/FBAS outputs

Audio and alarm inputs / outputs

Max. recording speed: 100 eld images per sec (PAL)

Memory capacity 250 GB / 500 GB / 750 GB

Maximum video resolution 720 x 576 pixels

SCSI port for archiving / memory expansion

Various recording criteria possible

Archiving/image transfer via USB and CD-RW

ATM/POS text display / 2x to 4x digital zoom

Telemetry control functions via RS-485 port

Network port (Ethernet) / IR remote control

Requirements for operation

Digital video recorder DTR connected

At least 1 camera connected

At least 1 monitor connected

Mouse connected, if DVR is to be controlled by mouse

Control options

Front panel

Remote control

Mouse

RAS program

●

8DTR-20XX

Connections on the rear

Note: Connections optionally for NTSC or PAL operation.

AUDIO IN 1 AUDIO IN 2 AUDIO IN 3 AUDIO IN 4 AUDIO OIT

VIDEO IN

LOOP

SPOT 1 SPOT 2

SPOT 3 SPOT 4

VIDEO OUT

SVHS OUT

NETWORKUSB RS-232C VGA SCSI

RS-485

ARI GNDAO1 AO2 AO3 AO4 AO5 AO6 AO7 AO8

GND GND GND

AO9

AO11AO10 AO12 AO13 AO14 AO15 AO16

GND

AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8

GND GND GND

AI9

AI11AI10 AI12 AI13 AI14 AI15 AI16

GND

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

1 2 3 4 5 6

13 12 111718 16 1415 910 8 7

No. Designation Functions/connections Example devices

1 VIDEO IN 1-16 Max. 16 video channels Cameras

2 LOOP 1-16 Max. 16 loop-through video channels Cameras

3 SVHS OUT S-VHS output Monitors

4 VIDEO OUT Video output Monitors

5 SPOT1 - SPOT4 Max. 4 video outputs Spot monitors

6 RS-485 External interface Keyboard, PTZ camera

7 NETWORK Network Network cable

8 ARI/GND Reset alarm

with external signal Switch

9 SCSI External storage media Hard disk

10 AO1 - AO16 Alarm outputs for external devices Siren, ashing light

11 VGA PC monitor PC monitor

12 RS-232C External interface Modem

13 USB External interface Drive, mouse

14 Reset switch Reset to factory defaults -

15 AI1 - AI16 Alarm inputs for external devices Sensors

16 AUDIO OUT Audio output Amplier, speakers

17 AUDIO IN 1 -

AUDIO IN 4 Max. 4 Audio inputs Microphone

18 Power supply Mains power connection -

DTR-20XX

Front panel controls

The following diagram and table shows the controls on the front panel of the DVR:

CAMERA PLAY/PAUSE

FFRW

FORWARD

BACKWARD

PANIC

HDD

NETWORK

POWER

JOG

DISPLAY

SEQUENCE

ALARM

SPOT

ZOOM

FREEZE

PTZ

1 32 4 5 6

14 13 1011 9 712 8

No. Designation Function

1 USB ports

2 Eject built-in CD-RW writer

3 1 to 16 Select cameras

Enter passwords

●

4 Menu navigation Navigation and selection within the menu

5 PANIC Start/end panic recording

6 Shuttle ring Innitely adjust playback speed

7 Jog dial

Change size of frame in picture-in-picture mode

Change numerical values in Setup menu

Frame-by-frame playback in Play mode

●

8Playback functions (primary assignment)

PTZ camera functions (secondary assignment)

9 POWER Power-on indicator when DVR is in operation

10 NETWORK Indicates Ethernet or modem connection

11 HDD Indicates hard disk operation

DISPLAY, SEQUENCE,

FREEZE, SPOT, ZOOM,

PTZ

Function buttons

13 ALARM Reset alarm

View event list

●

14 MENU Open/quit menu structure

10 DTR-20XX

Key to controls

Function buttons

Element Function

Change display mode

Switch video input by pressing and holding down button

●

Sequence On/Off

Freeze On/Off

PTZ camera functions On/Off

Zoom On/Off

Spot monitor assignments

PTZ camera functions

Element Function

Zoom in

Zoom out

Close-up

Wide-angle

Save preset

Load preset

Playback functions

Element Function

Select Search/Play function

Stop playback

●

Frame-by-frame rewind

Fast rewind

Start/pause playback

Fast forward

Frame-by-frame forward
