Vacmaster CC0101 Bedienungsanleitung

Use & Care Guide

MODEL NO. CC0101

Bagless Canister Vacuum Cleaner

www.vacmaster.com

Cleva North America, Inc.

Greenville, SC 29607

Made in China

(866) 384-8432

-3-

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

Failure to follow the warnings and instructions may result in electric shock, re

and/or serious injury.

WARNING - To reduce the risk of re, electric shock, or injury:

• Do not leave appliance when plugged in. Unplug from outlet when not in use

and before servicing.

• Do not use outdoors or on wet surfaces.

• Do not allow to be used as a toy. Close attention is necessary when used by

or near children.

• Use only as described in this manual. Use only manufacturer’s recommended

attachments.

• Do not use with damaged cord or plug. If appliance is not working as it should,

has been dropped, damaged, left outdoors, or dropped into water, return it to

a service center.

• Do not pull or carry by cord, use cord as a handle, close a door on cord, or

pull cord around sharp edges or corners. Do not run appliance over cord.

Keep cord away from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any object into openings. Do not use with any opening blocked;

keep free of dust, lint, hair, and anything that may reduce air ow.

• Keep hair, loose clothing, ngers, and all parts of body away from openings

and moving parts.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or combustible liquids, such as gasoline, or

use in areas where they may be present.

• Do not pick up anything that is burning or smoking, such as cigarettes,

matches, or hot ashes.

• Do not use without lters in place.

• Hold plug when rewinding onto cord reel. Do not allow plug to whip when

rewinding.

-4-

SAVE THESE INSTRUCTIONS

Household use only

FOR ONE YEAR from the date of sale, this product is warranted against defects

in material or workmanship when it is assembled, operated and maintained

according to all supplied instructions.

WITH PROOF OF SALE, a defective appliance will be replaced free of charge.

For warranty coverage details to obtain free replacement, visit the web page:

www.vacmaster.com or call (866) 384-8432.

• This warranty does not cover lters, which are expendable parts that

can wear out from normal use within the warranty period.

• This warranty is void if this product is ever used for other than private

household purposes.

• This warranty gives you specic legal rights, and you may also have other

rights which vary from state to state.

Bagless Canister Vacuum Cleaner

Model: CC0101

Rated Voltage: 120V AC

Rated Frequency: 60Hz

Nominal Current: 8.5A

TECHNICAL DATA

WARRANTY

-5-

GETTING TO KNOW YOUR VACUUM

REPLACEMENT PARTS

Available online at www.vacmaster.com or call (866) 384-8432.

Item Part No.

Attachment Holder 591018182

Crevice Tool 591018183

Dusting Brush 591018181

HEPA Filter 591018155

Air Outlet Filter 591018156

Exhaust Foam Filter 591018119

Floor Nozzle 591018185

Hose 591018168

Hose

Carpet/Bare

Floor Selector

Floor Nozzle

Cord Rewind

Button

On/Off Switch

Dust Cup

Crevice Tool

Air Outlet Filter

HEPA Filter

Power Cord

Exhaust Foam

Filter

Exhaust Foam Filter Cover

Air Outlet

Filter Holder

Attachment Holder

Dusting Brush

Dust Cup

Release Button

Suction

Control

Valve

Telescoping

Wand

Telescoping

Wand Length

Adjust Button

-6-

1. Insert the hose into the canister with the hose release button upward until you

hear a click. To remove, press button on the hose stopper and pull out.

IMPORTANT: Push the hose rmly into the canister until the hose latch tab snaps

into place.

2. Insert the telescoping wand into the handle and press together tightly.

3. Push and snap the attachment holder onto the wand.

GENERAL ASSEMBLY INSTRUCTIONS

Attachment Holder

WARNING!

DO NOT plug into electrical supply until assembly is complete. Failure to do so

could result in electrical shock or injury.

-7-

Using Your Vacuum Cleaner

Note: Make sure the vacuum cleaner is completely assembled and the dust cup

is empty before using. Do not use vacuum cleaner without lters in place.

1. Pull cord out of canister to desired length.

Note: The yellow mark on the power cord shows the ideal cord length. Do not

extend the power cord beyond the red mark.

5. This vacuum cleaner is equipped with onboard attachment storage. The

dusting brush and crevice tool are stored in the attachment holder as shown.

OPERATING INSTRUCTIONS

Red Mark

Dusting Brush

Crevice Tool

Yellow Mark

4. Insert the desired accessories into the wand and press together tightly .

-8-

4. Once you have completed vacuuming, press the on/off button to turn the

vacuum off and unplug the power cord from the outlet. Then press the cord

rewind button to rewind the power cord.

3. Press the on/off switch to turn the vacuum on.

On/Off Switch

Cord Rewind Button

2. Plug the power cord into an outlet located near the oor.

WARNING

To reduce the risk of electric shock, this vacuum cleaner has a polarized plug

(one blade is wider than the other). This plug will t in a polarized outlet only

one way. If the plug does not t fully in the outlet, reverse the plug. If it still does

not t, contact a qualied electrician to install the proper outlet. Do not change

the plug in any way.

Note:

• Guide the cord with one hand to ensure that it does not whip causing damage.

• It is recommended to rewind the cord fractionally 3-4 times to avoid personal

injury or the cord getting stuck.

• When the cord is stuck, pull the cord out and depress the cord rewind button

to rewind the cord. Do not over-pull the cord.

-9-

Using the Attachments

• Floor Nozzle

Use the standard setting for carpet cleaning. Depress the carpet/bare oor

selector to transition to bare oor cleaning.

For Carpet For Bare Floor

• Telescoping Wand

Adjust the length of the wand to your desired height by pushing the slider adjust

button.

• Hose

Slide the suction control valve to change vacuum cleaner suction for different

fabric and carpet weights. Opening the valve decreases suction for lightweight

rugs. Closing the valve increases suction for upholstery and carpets.

WARNING

• The cord moves rapidly when rewinding. Keep children away and provide a

clear path when rewinding the cord to prevent personal injury.

• DO NOT use outlets above counters. Damage from cord to items in

surrounding area could occur.

Carpet/Bare Floor Selector

Increase Suction

Decrease Suction

Suction Control Valve

Wand Adjust Button

-10-

Note:You can also choose to use your vacuum cleaner by inserting the crevice

tool or the dusting brush into the hose directly.

• Dusting Brush: For vacuuming fragile or easily scratched items, such as

furniture and drapes.

Storing Your Vacuum

1. This vacuum provides two ways of storage.

1) The oor nozzle stores into the slot located on the back of the canister as

shown in Figure A.

2) With the oor nozzle attached, the telescoping wand stores into the slot

located on the bottom of the canister as shown in Figure B.

2. Store crevice tool and dusting brush in attachment holder located on the

telescoping wand.

3. Press the cord rewind button to rewind the power cord.

4. Store the vacuum cleaner in a dry, indoor area.

A B

• Crevice Tool: For vacuuming edges and gaps.

-11-

Dust Cup Release Button

Dust Release Button

MAINTAINING YOUR VACUUM

1. Press the dust cup release button as shown to separate the dust cup & lters

from the canister.

2. Hold the handle and position the dust cup over a waste receptacle. Press the

dust release button to open dust cup lid and allow contents to drop into waste

receptacle.

3. Reinstall and insert the dust cup into the main body until you hear a click.

Emptying the Dust Cup

Note: For best performance, empty dust cup after every use. Never operate

vacuum cleaner without dust cup and lter in place.

CAUTION

To reduce the risk of shock, disconnect the power cord, and turn off before

performing any service or maintenance.
